SDO HMI 2014-04-03 00:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64.28 | 190.49 | 39.30 | 116.16 | 16.37 | 29.84 | -27.71 | 49.86 | 0.5852 | -184.1 | -107.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-03 00:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.03 | 126.72 | 4.20 | 76.22 | 15.76 | 31.49 | -26.07 | 49.04 | 0.5622 | -1155.0 | -370.0 | |
| 21.69 | -1.00 | 13.03 | -1.00 | 16.13 | 31.26 | -26.29 | 48.77 | 0.5680 | -1015.6 | 999999 | |
| 3.07 | -1.00 | 1.85 | -1.00 | 15.85 | 31.02 | -26.53 | 49.41 | 0.5680 | -961.7 | 999999 | |
| 0.00 | 2.28 | 0.00 | 1.37 | 15.50 | 30.86 | -26.69 | 50.06 | 0.5667 | -307.0 | -277.6 | |
| 0.70 | -1.00 | 0.43 | -1.00 | 16.33 | 30.64 | -26.91 | 49.16 | 0.5764 | -361.6 | 999999 | |
| 1.67 | -1.00 | 1.01 | -1.00 | 15.97 | 30.62 | -26.93 | 49.66 | 0.5735 | -819.5 | 999999 | |
| 9.22 | -1.00 | 5.59 | -1.00 | 16.03 | 30.19 | -27.36 | 50.03 | 0.5786 | -751.0 | 999999 | |
| 0.00 | 1.76 | 0.00 | 1.07 | 16.34 | 29.79 | -27.76 | 50.00 | 0.5857 | -185.0 | -189.2 | |
| 0.00 | 0.97 | 0.00 | 0.59 | 16.21 | 29.74 | -27.81 | 50.23 | 0.5851 | -330.0 | -222.4 | |
| 0.00 | 1.32 | 0.00 | 0.80 | 16.16 | 29.46 | -28.09 | 50.57 | 0.5877 | 178.0 | 178.4 | |
| 0.00 | 3.78 | 0.00 | 2.33 | 16.68 | 28.95 | -28.60 | 50.37 | 0.5976 | 650.0 | 483.3 | |
| 0.00 | 1.23 | 0.00 | 0.76 | 16.21 | 28.71 | -28.84 | 51.24 | 0.5963 | -680.0 | -470.5 | |
| 0.00 | 1.23 | 0.00 | 0.77 | 17.14 | 28.27 | -29.28 | 50.41 | 0.6088 | 578.0 | 462.6 | |
| 0.00 | 0.70 | 0.00 | 0.44 | 17.94 | 28.05 | -29.50 | 49.57 | 0.6177 | 617.0 | 501.6 | |
| 0.00 | 0.53 | 0.00 | 0.33 | 17.02 | 28.18 | -29.37 | 50.65 | 0.6087 | -224.0 | -233.2 | |
| 0.00 | 1.32 | 0.00 | 0.83 | 18.25 | 27.81 | -29.74 | 49.39 | 0.6228 | 601.0 | 437.3 | |
| 0.00 | 0.61 | 0.00 | 0.38 | 15.33 | 28.24 | -29.31 | 52.88 | 0.5943 | 626.0 | 552.1 | |
| 0.00 | 0.88 | 0.00 | 0.54 | 15.34 | 28.02 | -29.53 | 53.07 | 0.5968 | 583.0 | 466.7 | |
| 11.24 | 24.06 | 7.06 | 15.10 | 17.25 | 27.60 | -29.95 | 50.89 | 0.6168 | 870.9 | 461.9 | |
| 1.93 | 4.48 | 1.21 | 2.81 | 16.53 | 27.03 | -30.52 | 52.34 | 0.6172 | 808.7 | 586.4 | |
| 1.41 | 12.47 | 0.89 | 7.93 | 17.79 | 26.81 | -30.75 | 50.90 | 0.6295 | 759.1 | 534.1 | |
| 0.00 | 1.93 | 0.00 | 1.21 | 16.21 | 27.09 | -30.46 | 52.73 | 0.6140 | 759.0 | 673.9 | |
| 0.00 | 0.97 | 0.00 | 0.60 | 16.08 | 27.11 | -30.44 | 52.89 | 0.6127 | 862.0 | 693.6 | |
| 5.53 | -21.00 | 3.52 | -21.00 | 17.54 | 26.60 | -30.96 | 51.41 | 0.6298 | 728.0 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.79 | 16.75 | 25.64 | -31.91 | 53.26 | 0.6339 | 774.0 | 682.3 | |
| 0.79 | 2.02 | 0.51 | 1.29 | 16.92 | 25.50 | -32.06 | 53.16 | 0.6367 | 703.9 | 603.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
