SDO HMI 2014-04-03 13:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 59.21 | 353.82 | 38.80 | 232.20 | 12.43 | 13.84 | -36.59 | 62.63 | 0.6577 | -711.1 | -311.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-03 13:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.14 | 0.00 | 0.70 | 4.45 | 15.83 | -34.60 | 73.42 | 0.5929 | 741.0 | 583.8 | |
| 54.90 | 339.78 | 35.92 | 222.67 | 12.47 | 14.05 | -36.38 | 62.45 | 0.6555 | -1115.4 | -352.8 | |
| 3.78 | -2.00 | 2.52 | -2.00 | 12.65 | 12.78 | -37.64 | 62.99 | 0.6712 | -540.7 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.53 | 11.44 | 12.16 | -38.26 | 65.02 | 0.6719 | -166.0 | -168.6 | |
| 0.00 | 1.41 | 0.00 | 0.95 | 11.06 | 11.36 | -39.07 | 65.99 | 0.6794 | 666.0 | 572.4 | |
| 0.53 | 3.95 | 0.36 | 2.69 | 12.05 | 11.04 | -39.39 | 64.82 | 0.6881 | 728.2 | 690.7 | |
| 0.00 | 0.61 | 0.00 | 0.42 | 11.63 | 10.87 | -39.55 | 65.49 | 0.6879 | 633.0 | 539.0 | |
| 0.00 | 1.14 | 0.00 | 0.77 | 10.81 | 10.88 | -39.54 | 66.58 | 0.6838 | 552.0 | 488.2 | |
| 0.00 | 1.41 | 0.00 | 0.95 | 11.00 | 10.81 | -39.61 | 66.36 | 0.6855 | 513.0 | 468.1 | |
| 0.00 | 0.61 | 0.00 | 0.42 | 11.65 | 10.55 | -39.88 | 65.63 | 0.6917 | 614.0 | 520.4 | |
| 0.00 | 0.44 | 0.00 | 0.30 | 11.31 | 10.48 | -39.94 | 66.12 | 0.6908 | 426.0 | 423.4 | |
| 0.00 | 0.70 | 0.00 | 0.48 | 11.50 | 10.41 | -40.01 | 65.90 | 0.6925 | 479.0 | 434.5 | |
| 0.00 | 1.84 | 0.00 | 1.32 | 12.84 | 8.16 | -42.27 | 65.33 | 0.7240 | 567.0 | 524.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
