SDO HMI 2014-04-04 11:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 80.18 | 399.13 | 46.20 | 230.15 | 12.30 | 13.77 | -24.56 | 52.65 | 0.5131 | -848.8 | -334.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-04 11:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.76 | 0.00 | 0.96 | 5.00 | 15.88 | -22.44 | 63.66 | 0.4262 | 774.0 | 488.2 | |
| 77.28 | 379.00 | 44.52 | 218.50 | 12.47 | 13.93 | -24.40 | 52.19 | 0.5125 | -1243.7 | -381.4 | |
| 2.90 | -2.00 | 1.68 | -2.00 | 12.61 | 13.04 | -25.29 | 52.97 | 0.5243 | -735.5 | 999999 | |
| 0.00 | 1.85 | 0.00 | 1.07 | 12.23 | 12.50 | -25.83 | 54.14 | 0.5275 | -593.0 | -456.6 | |
| 0.00 | 1.23 | 0.00 | 0.71 | 11.57 | 12.53 | -25.80 | 55.16 | 0.5215 | -458.0 | -355.7 | |
| 0.00 | 1.32 | 0.00 | 0.77 | 11.89 | 12.40 | -25.93 | 54.79 | 0.5258 | -471.0 | -398.5 | |
| 0.00 | 1.41 | 0.00 | 0.81 | 10.18 | 12.08 | -26.25 | 57.88 | 0.5160 | 817.0 | 642.9 | |
| 0.00 | 0.44 | 0.00 | 0.26 | 11.51 | 11.85 | -26.47 | 55.95 | 0.5293 | -307.0 | -271.6 | |
| 0.00 | 0.88 | 0.00 | 0.51 | 10.01 | 11.76 | -26.57 | 58.49 | 0.5188 | 660.0 | 570.8 | |
| 0.00 | 1.14 | 0.00 | 0.67 | 10.90 | 11.40 | -26.93 | 57.37 | 0.5301 | 770.0 | 576.0 | |
| 0.00 | 0.97 | 0.00 | 0.57 | 12.21 | 11.09 | -27.24 | 55.60 | 0.5442 | 791.0 | 677.9 | |
| 0.00 | 1.49 | 0.00 | 0.88 | 11.52 | 10.92 | -27.40 | 56.84 | 0.5408 | 880.0 | 762.2 | |
| 0.00 | 4.92 | 0.00 | 2.78 | 3.42 | 11.36 | -26.96 | 70.81 | 0.4812 | 817.0 | 610.2 | |
| 0.00 | 0.62 | 0.00 | 0.37 | 13.36 | 9.13 | -29.19 | 55.71 | 0.5766 | 547.0 | 460.9 | |
| 0.00 | 1.05 | 0.00 | 0.65 | 12.38 | 7.05 | -31.27 | 58.95 | 0.5941 | 634.0 | 494.4 | |
| 0.00 | 1.05 | 0.00 | 0.64 | 9.21 | 6.67 | -31.66 | 64.07 | 0.5783 | 645.0 | 562.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
