SDO HMI 2014-04-06 09:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.78 | 86.97 | 10.15 | 49.49 | 17.80 | 30.39 | 17.36 | 324.82 | 0.4949 | -542.3 | -357.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-06 09:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.82 | 76.67 | 7.89 | 43.72 | 17.78 | 30.85 | 17.82 | 324.05 | 0.4985 | -1066.6 | -486.4 | |
| 3.96 | -1.00 | 2.26 | -1.00 | 17.67 | 30.58 | 17.55 | 324.34 | 0.4948 | -1265.9 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.55 | 18.32 | 30.28 | 17.25 | 325.58 | 0.5001 | -725.0 | -599.0 | |
| 0.00 | 0.97 | 0.00 | 0.55 | 18.87 | 29.87 | 16.84 | 326.85 | 0.5034 | -657.0 | -543.3 | |
| 0.00 | 1.67 | 0.00 | 0.95 | 18.84 | 27.70 | 14.66 | 330.31 | 0.4858 | 649.0 | 567.7 | |
| 0.00 | 2.11 | 0.00 | 1.18 | 18.02 | 26.74 | 13.71 | 331.06 | 0.4678 | 553.0 | 472.6 | |
| 0.00 | 2.82 | 0.00 | 1.57 | 17.79 | 26.63 | 13.60 | 331.01 | 0.4639 | 548.0 | 657.1 | |
| 0.00 | 0.53 | 0.00 | 0.29 | 17.60 | 25.90 | 12.87 | 332.13 | 0.4561 | 622.0 | 586.3 | |
| 0.00 | 1.23 | 0.00 | 0.68 | 17.47 | 25.83 | 12.80 | 332.12 | 0.4537 | 986.0 | 879.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
