SDO HMI 2014-04-06 10:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.23 | 77.03 | 10.42 | 44.00 | 17.80 | 30.45 | 17.97 | 323.89 | 0.5002 | -604.3 | -375.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-06 10:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.17 | 0.00 | 1.81 | 17.39 | 31.19 | 18.70 | 322.24 | 0.5018 | -912.0 | -703.7 | |
| 10.39 | 67.25 | 5.95 | 38.48 | 17.77 | 30.93 | 18.45 | 323.10 | 0.5039 | -1037.7 | -485.6 | |
| 3.61 | -2.00 | 2.06 | -2.00 | 17.93 | 30.62 | 18.13 | 323.76 | 0.5029 | -1037.9 | 999999 | |
| 4.23 | -2.00 | 2.41 | -2.00 | 17.66 | 30.55 | 18.07 | 323.53 | 0.4992 | -1263.7 | 999999 | |
| 0.00 | 2.29 | 0.00 | 1.30 | 18.86 | 27.70 | 15.22 | 329.41 | 0.4902 | 648.0 | 529.2 | |
| 0.00 | 1.41 | 0.00 | 0.79 | 18.07 | 26.72 | 14.23 | 330.20 | 0.4724 | 653.0 | 545.9 | |
| 0.00 | 1.50 | 0.00 | 0.83 | 17.45 | 25.83 | 13.34 | 331.10 | 0.4574 | 931.0 | 870.1 | |
| 0.00 | 1.41 | 0.00 | 0.79 | 18.08 | 25.78 | 13.29 | 331.87 | 0.4655 | 720.0 | 576.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
