SDO HMI 2014-04-06 11:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.48 | 80.69 | 10.61 | 46.26 | 17.82 | 30.39 | 18.46 | 323.18 | 0.5047 | -415.2 | -345.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-06 11:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.88 | 0.00 | 0.51 | 17.52 | 31.42 | 19.49 | 321.27 | 0.5105 | -458.0 | -353.7 | |
| 6.60 | 71.55 | 3.79 | 41.08 | 17.70 | 30.94 | 19.01 | 322.19 | 0.5081 | -1018.1 | -470.0 | |
| 8.10 | -2.00 | 4.65 | -2.00 | 17.92 | 30.64 | 18.70 | 322.91 | 0.5079 | -1019.4 | 999999 | |
| 3.78 | -2.00 | 2.17 | -2.00 | 17.68 | 30.54 | 18.61 | 322.75 | 0.5043 | -1223.7 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.71 | 18.30 | 30.28 | 18.34 | 323.90 | 0.5092 | -652.0 | -489.9 | |
| 0.00 | 1.23 | 0.00 | 0.70 | 18.84 | 27.65 | 15.72 | 328.59 | 0.4938 | 754.0 | 578.1 | |
| 0.00 | 0.88 | 0.00 | 0.50 | 18.64 | 27.57 | 15.63 | 328.50 | 0.4906 | 674.0 | 524.8 | |
| 0.00 | 0.97 | 0.00 | 0.54 | 17.44 | 27.10 | 15.16 | 327.90 | 0.4715 | 716.0 | 618.8 | |
| 0.00 | 1.58 | 0.00 | 0.89 | 18.12 | 26.70 | 14.76 | 329.35 | 0.4771 | 653.0 | 509.4 | |
| 0.00 | 0.70 | 0.00 | 0.40 | 17.88 | 26.55 | 14.61 | 329.35 | 0.4728 | 864.0 | 771.8 | |
| 0.00 | 1.67 | 0.00 | 0.93 | 17.47 | 25.83 | 13.90 | 330.13 | 0.4618 | 976.0 | 832.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
