SDO HMI 2014-04-06 17:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 76.70 | 412.81 | 40.31 | 217.01 | 12.62 | 13.57 | 4.93 | 345.43 | 0.3347 | -1257.5 | -417.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-06 17:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 76.44 | 400.85 | 40.17 | 210.77 | 12.61 | 13.64 | 5.00 | 345.22 | 0.3348 | -1530.3 | -428.0 | |
| 0.26 | -1.00 | 0.14 | -1.00 | 13.24 | 13.34 | 4.70 | 346.51 | 0.3438 | -939.0 | 999999 | |
| 0.00 | 1.32 | 0.00 | 0.68 | 10.62 | 12.89 | 4.26 | 345.85 | 0.2998 | 818.0 | 620.6 | |
| 0.00 | 1.32 | 0.00 | 0.69 | 13.21 | 12.17 | 3.53 | 349.78 | 0.3392 | -767.0 | -627.9 | |
| 0.00 | 0.70 | 0.00 | 0.37 | 15.12 | 11.86 | 3.22 | 351.52 | 0.3694 | 493.0 | 339.0 | |
| 0.00 | 1.32 | 0.00 | 0.69 | 11.62 | 11.56 | 2.92 | 350.73 | 0.3116 | -888.0 | -674.9 | |
| 0.00 | 1.32 | 0.00 | 0.70 | 14.22 | 11.41 | 2.77 | 352.35 | 0.3538 | -849.0 | -645.2 | |
| 0.00 | 2.64 | 0.00 | 1.38 | 12.22 | 11.26 | 2.62 | 351.95 | 0.3207 | -630.0 | -431.0 | |
| 0.00 | 1.23 | 0.00 | 0.64 | 12.41 | 11.20 | 2.56 | 352.21 | 0.3237 | -588.0 | -464.4 | |
| 0.00 | 0.97 | 0.00 | 0.50 | 11.27 | 10.85 | 2.21 | 352.81 | 0.3041 | 848.0 | 743.0 | |
| 0.00 | 1.14 | 0.00 | 0.59 | 11.05 | 9.29 | 0.65 | 357.84 | 0.2983 | 843.0 | 727.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
