SDO HMI 2014-04-06 18:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.64 | 58.41 | 6.26 | 34.40 | 17.72 | 30.57 | 22.49 | 317.54 | 0.5417 | -623.5 | -524.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-06 18:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.20 | 0.00 | 1.30 | 17.40 | 31.10 | 23.02 | 316.43 | 0.5436 | -829.0 | -603.0 | |
| 6.86 | 52.95 | 4.04 | 31.21 | 17.61 | 30.86 | 22.78 | 317.02 | 0.5434 | -993.9 | -570.2 | |
| 2.11 | -2.00 | 1.24 | -2.00 | 17.96 | 30.46 | 22.38 | 317.97 | 0.5430 | -950.2 | 999999 | |
| 1.67 | -2.00 | 0.98 | -2.00 | 17.66 | 30.39 | 22.30 | 317.67 | 0.5392 | -1216.7 | 999999 | |
| 0.00 | 1.41 | 0.00 | 0.83 | 19.21 | 29.54 | 21.46 | 320.71 | 0.5477 | -711.0 | -567.4 | |
| 0.00 | 0.79 | 0.00 | 0.46 | 18.70 | 27.51 | 19.43 | 322.82 | 0.5234 | 624.0 | 548.8 | |
| 0.00 | 1.06 | 0.00 | 0.60 | 17.52 | 25.98 | 17.90 | 323.61 | 0.4959 | 905.0 | 757.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
