SDO HMI 2014-04-07 13:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 12.92 | 0.00 | 6.65 | -17.49 | 348.81 | -8.83 | 144.41 | 0.2532 | -823.2 | -636.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-07 13:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.40 | -17.98 | 355.50 | -2.15 | 170.15 | 0.2091 | -996.0 | -834.8 | |
| 0.00 | 1.32 | 0.00 | 0.66 | -13.51 | 355.52 | -2.12 | 164.29 | 0.1337 | -860.0 | -569.2 | |
| 0.00 | 1.76 | 0.00 | 0.90 | -19.28 | 352.04 | -5.60 | 157.95 | 0.2466 | -735.0 | -552.4 | |
| 0.00 | 1.58 | 0.00 | 0.80 | -15.77 | 351.05 | -6.59 | 146.65 | 0.2018 | -923.0 | -717.9 | |
| 0.00 | 1.23 | 0.00 | 0.62 | -9.53 | 349.87 | -7.77 | 114.21 | 0.1469 | -792.0 | -723.9 | |
| 0.00 | 1.23 | 0.00 | 0.65 | -23.14 | 348.13 | -9.51 | 152.62 | 0.3319 | -593.0 | -403.8 | |
| 0.00 | 1.58 | 0.00 | 0.82 | -17.77 | 345.13 | -12.51 | 134.66 | 0.2913 | -861.0 | -623.4 | |
| 0.00 | 2.02 | 0.00 | 1.05 | -17.92 | 345.02 | -12.62 | 134.80 | 0.2943 | -855.0 | -764.0 | |
| 0.00 | 1.41 | 0.00 | 0.75 | -21.21 | 342.10 | -15.55 | 136.52 | 0.3647 | -794.0 | -567.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
