SDO HMI 2014-04-07 16:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 13.91 | 0.00 | 7.08 | -17.43 | 350.71 | -5.28 | 154.76 | 0.2358 | -651.0 | -592.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-07 16:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.53 | 0.00 | 0.29 | -22.95 | 17.22 | 21.23 | 228.44 | 0.4475 | 791.0 | 611.2 | |
| 0.00 | 1.41 | 0.00 | 0.71 | -17.99 | 355.49 | -0.50 | 177.66 | 0.2062 | -944.0 | -885.4 | |
| 0.00 | 2.90 | 0.00 | 1.48 | -19.32 | 352.08 | -3.91 | 164.23 | 0.2381 | -676.0 | -422.8 | |
| 0.00 | 1.06 | 0.00 | 0.53 | -15.82 | 351.06 | -4.93 | 153.85 | 0.1884 | -837.0 | -745.4 | |
| 0.00 | 0.70 | 0.00 | 0.35 | -14.44 | 349.60 | -6.39 | 143.34 | 0.1813 | -757.0 | -457.8 | |
| 0.00 | 3.17 | 0.00 | 1.60 | -15.89 | 349.37 | -6.62 | 146.86 | 0.2038 | -764.0 | -612.4 | |
| 0.00 | 1.41 | 0.00 | 0.72 | -16.16 | 346.87 | -9.12 | 138.98 | 0.2331 | -856.0 | -712.2 | |
| 0.00 | 1.32 | 0.00 | 0.68 | -17.99 | 344.98 | -11.01 | 138.73 | 0.2766 | -913.0 | -816.9 | |
| 0.00 | 1.41 | 0.00 | 0.72 | -17.59 | 345.01 | -10.98 | 137.78 | 0.2715 | -903.0 | -717.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
