SDO HMI 2014-04-08 14:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.60 | 26.16 | 5.44 | 14.83 | -2.70 | 314.91 | -28.98 | 84.55 | 0.4882 | 284.2 | 168.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-08 14:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.11 | 0.00 | 1.18 | -1.66 | 316.32 | -27.58 | 81.99 | 0.4692 | 1012.0 | 811.1 | |
| 1.67 | 12.16 | 0.94 | 6.84 | -2.48 | 315.79 | -28.10 | 83.88 | 0.4753 | 944.8 | 719.1 | |
| 4.23 | -2.00 | 2.38 | -2.00 | -2.20 | 315.73 | -28.16 | 83.33 | 0.4768 | 901.3 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.70 | -2.30 | 315.32 | -28.58 | 83.66 | 0.4829 | 792.0 | 626.4 | |
| 3.70 | 9.60 | 2.12 | 5.50 | -3.39 | 313.66 | -30.23 | 86.28 | 0.5057 | -840.5 | -610.7 | |
| 0.00 | 1.06 | 0.00 | 0.61 | -3.65 | 313.55 | -30.35 | 86.83 | 0.5070 | -657.0 | -460.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
