SDO HMI 2014-04-09 07:05:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 12.52 | 0.00 | 7.66 | -7.65 | 10.48 | 35.99 | 265.28 | 0.5863 | 394.0 | 323.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-09 07:05:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.85 | 0.00 | 1.15 | -5.23 | 11.49 | 37.00 | 269.34 | 0.6016 | 741.0 | 627.0 | |
| 0.00 | 1.41 | 0.00 | 0.88 | -8.01 | 11.80 | 37.31 | 264.69 | 0.6051 | 697.0 | 605.9 | |
| 0.00 | 1.59 | 0.00 | 0.99 | -8.16 | 12.40 | 37.91 | 264.46 | 0.6133 | 710.0 | 583.8 | |
| 0.00 | 2.56 | 0.00 | 1.50 | -7.60 | 6.88 | 32.39 | 265.32 | 0.5348 | -653.0 | -574.0 | |
| 0.00 | 1.76 | 0.00 | 1.09 | -8.19 | 11.78 | 37.29 | 264.40 | 0.6047 | 1027.0 | 861.5 | |
| 0.00 | 0.97 | 0.00 | 0.57 | -7.71 | 6.72 | 32.23 | 265.12 | 0.5325 | -659.0 | -544.5 | |
| 0.00 | 1.32 | 0.00 | 0.82 | -8.57 | 11.65 | 37.16 | 263.76 | 0.6031 | 587.0 | 563.0 | |
| 0.00 | 1.06 | 0.00 | 0.66 | -8.68 | 11.86 | 37.37 | 263.58 | 0.6061 | 702.0 | 624.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
