SDO HMI 2014-04-10 02:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.67 | 32.61 | 5.03 | 32.10 | -9.50 | 24.20 | 60.13 | 262.39 | 0.8623 | 105.3 | 97.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-10 02:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.26 | 0.00 | 3.61 | -7.37 | 27.92 | 63.85 | 264.75 | 0.8958 | 483.0 | 435.2 | |
| 3.17 | 5.29 | 3.42 | 5.70 | -8.74 | 27.21 | 63.14 | 263.25 | 0.8898 | 417.6 | 398.9 | |
| 1.15 | 2.38 | 1.24 | 2.57 | -9.25 | 27.30 | 63.23 | 262.67 | 0.8904 | 331.2 | 228.5 | |
| 0.00 | 1.41 | 0.00 | 1.51 | -7.89 | 26.90 | 62.83 | 264.22 | 0.8876 | 300.0 | 301.6 | |
| 0.00 | 0.79 | 0.00 | 0.84 | -8.08 | 26.76 | 62.68 | 264.01 | 0.8864 | 541.0 | 475.4 | |
| 0.35 | 1.50 | 0.37 | 1.58 | -8.41 | 26.51 | 62.44 | 263.65 | 0.8843 | 426.5 | 424.4 | |
| 0.00 | 1.15 | 0.00 | 1.21 | -8.26 | 26.47 | 62.40 | 263.82 | 0.8840 | 558.0 | 470.6 | |
| 0.00 | 1.50 | 0.00 | 1.57 | -8.84 | 26.44 | 62.37 | 263.17 | 0.8836 | 377.0 | 281.1 | |
| 0.00 | 1.23 | 0.00 | 1.28 | -8.36 | 26.04 | 61.97 | 263.73 | 0.8805 | 235.0 | 222.1 | |
| 0.00 | 0.88 | 0.00 | 0.91 | -9.68 | 25.85 | 61.77 | 262.23 | 0.8785 | 326.0 | 330.1 | |
| 0.00 | 0.53 | 0.00 | 0.54 | -9.76 | 25.68 | 61.60 | 262.15 | 0.8771 | 559.0 | 492.8 | |
| 0.00 | 0.79 | 0.00 | 0.80 | -9.91 | 25.08 | 61.01 | 262.00 | 0.8721 | 412.0 | 379.9 | |
| 0.00 | 3.35 | 0.00 | 3.09 | -12.86 | 22.07 | 58.00 | 258.56 | 0.8456 | -544.0 | -396.7 | |
| 0.00 | 1.41 | 0.00 | 1.30 | -12.68 | 21.95 | 57.88 | 258.76 | 0.8445 | -535.0 | -425.2 | |
| 0.00 | 0.79 | 0.00 | 0.67 | -13.21 | 18.24 | 54.17 | 258.00 | 0.8091 | -372.0 | -279.8 | |
| 0.00 | 1.59 | 0.00 | 1.25 | -11.18 | 15.52 | 51.44 | 260.47 | 0.7802 | -192.0 | -165.2 | |
| 0.00 | 2.03 | 0.00 | 1.57 | -9.54 | 14.76 | 50.68 | 262.57 | 0.7717 | -509.0 | -366.1 | |
| 0.00 | 0.35 | 0.00 | 0.27 | -9.69 | 14.74 | 50.66 | 262.38 | 0.7715 | -567.0 | -525.8 | |
| 0.00 | 1.23 | 0.00 | 0.95 | -10.39 | 14.26 | 50.19 | 261.45 | 0.7663 | -618.0 | -507.6 | |
| 0.00 | 1.15 | 0.00 | 0.88 | -11.16 | 14.24 | 50.17 | 260.45 | 0.7663 | -452.0 | -355.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
