SDO HMI 2014-04-10 06:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.00 | 354.41 | 50.20 | 281.68 | 11.84 | 273.48 | -48.40 | 69.63 | 0.7818 | -489.3 | -192.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-10 06:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.88 | 0.00 | 0.64 | 11.59 | 278.11 | -43.77 | 68.03 | 0.7331 | -565.0 | -475.6 | |
| 0.00 | 2.03 | 0.00 | 1.53 | 9.86 | 275.44 | -46.44 | 71.35 | 0.7559 | -429.0 | -394.3 | |
| 46.94 | 263.35 | 35.86 | 201.50 | 11.07 | 275.11 | -46.77 | 69.95 | 0.7635 | -1151.5 | -321.4 | |
| 0.00 | 2.38 | 0.00 | 1.91 | 12.48 | 273.13 | -48.75 | 68.99 | 0.7886 | -386.0 | -420.1 | |
| 0.00 | 1.15 | 0.00 | 0.91 | 11.81 | 273.25 | -48.63 | 69.75 | 0.7852 | -511.0 | -444.8 | |
| 0.00 | 0.97 | 0.00 | 0.78 | 12.20 | 273.11 | -48.77 | 69.34 | 0.7879 | -349.0 | -317.7 | |
| 0.00 | 1.41 | 0.00 | 1.12 | 10.84 | 273.24 | -48.64 | 70.94 | 0.7822 | -645.0 | -549.3 | |
| 0.00 | 0.26 | 0.00 | 0.21 | 11.67 | 273.00 | -48.88 | 70.01 | 0.7873 | -335.0 | -364.0 | |
| 0.00 | 1.24 | 0.00 | 1.00 | 12.41 | 272.77 | -49.11 | 69.20 | 0.7920 | -587.0 | -418.5 | |
| 0.00 | 0.79 | 0.00 | 0.64 | 11.44 | 272.82 | -49.06 | 70.37 | 0.7883 | -320.0 | -279.1 | |
| 0.00 | 0.71 | 0.00 | 0.57 | 11.08 | 272.62 | -49.26 | 70.88 | 0.7892 | -342.0 | -251.5 | |
| 0.00 | 1.24 | 0.00 | 1.03 | 13.12 | 271.43 | -50.45 | 68.86 | 0.8073 | 673.0 | 550.8 | |
| 0.00 | 1.32 | 0.00 | 1.08 | 9.91 | 271.35 | -50.52 | 72.73 | 0.7985 | -468.0 | -455.1 | |
| 4.32 | 60.17 | 3.86 | 53.65 | 14.32 | 268.95 | -52.93 | 68.36 | 0.8339 | 602.6 | 199.9 | |
| 9.09 | -14.00 | 8.08 | -14.00 | 13.91 | 268.94 | -52.94 | 68.83 | 0.8328 | 829.0 | 999999 | |
| 0.00 | 1.24 | 0.00 | 1.12 | 14.95 | 268.57 | -53.30 | 67.76 | 0.8391 | 422.0 | 354.7 | |
| 0.62 | 1.59 | 0.56 | 1.44 | 14.88 | 268.34 | -53.54 | 67.93 | 0.8409 | 518.6 | 406.9 | |
| 0.00 | 3.97 | 0.00 | 3.65 | 15.25 | 268.10 | -53.78 | 67.59 | 0.8441 | 628.0 | 506.2 | |
| 0.97 | 2.91 | 0.90 | 2.69 | 15.49 | 267.95 | -53.93 | 67.37 | 0.8460 | 419.7 | 300.6 | |
| 0.00 | 1.41 | 0.00 | 1.29 | 14.99 | 268.14 | -53.74 | 67.87 | 0.8430 | 271.0 | 314.2 | |
| 1.06 | 3.09 | 0.94 | 2.75 | 13.08 | 268.58 | -53.30 | 69.90 | 0.8338 | 325.6 | -57.0 | |
| 0.00 | 0.71 | 0.00 | 0.66 | 14.01 | 267.05 | -54.83 | 69.35 | 0.8497 | 323.0 | 316.9 | |
| 0.00 | 0.71 | 0.00 | 0.67 | 14.54 | 266.80 | -55.08 | 68.83 | 0.8532 | 173.0 | 239.5 | |
| 0.00 | 0.88 | 0.00 | 0.84 | 13.34 | 266.03 | -55.85 | 70.42 | 0.8567 | 371.0 | 307.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
