SDO HMI 2014-04-13 15:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.89 | 257.54 | 23.52 | 138.01 | 12.05 | 263.62 | -13.73 | 37.49 | 0.3829 | -1362.1 | -411.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-13 15:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.56 | 255.86 | 14.76 | 137.10 | 12.12 | 263.78 | -13.56 | 37.04 | 0.3822 | -1440.0 | -410.3 | |
| 16.07 | -1.00 | 8.62 | -1.00 | 11.94 | 263.45 | -13.90 | 38.02 | 0.3832 | -1374.6 | 999999 | |
| 0.26 | -1.00 | 0.14 | -1.00 | 12.01 | 263.06 | -14.28 | 38.66 | 0.3879 | -806.7 | 999999 | |
| 0.00 | 1.68 | 0.00 | 0.91 | 11.78 | 261.07 | -16.27 | 42.73 | 0.4060 | -737.0 | -588.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
