SDO HMI 2014-04-14 15:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 71.40 | 401.89 | 37.77 | 212.54 | 11.77 | 274.99 | 10.85 | 328.25 | 0.3521 | -1071.3 | -383.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-14 15:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 70.25 | 389.18 | 37.16 | 205.83 | 11.70 | 275.16 | 11.02 | 327.73 | 0.3522 | -1473.7 | -419.7 | |
| 0.00 | 1.06 | 0.00 | 0.55 | 10.08 | 273.67 | 9.53 | 328.85 | 0.3166 | -810.0 | -718.4 | |
| 0.00 | 0.53 | 0.00 | 0.28 | 12.72 | 270.96 | 6.82 | 339.76 | 0.3366 | 719.0 | 584.5 | |
| 0.00 | 1.94 | 0.00 | 1.02 | 13.18 | 270.23 | 6.09 | 342.23 | 0.3399 | 785.0 | 672.5 | |
| 0.00 | 1.59 | 0.00 | 0.84 | 12.99 | 269.89 | 5.75 | 343.01 | 0.3352 | 1122.0 | 977.2 | |
| 0.00 | 2.03 | 0.00 | 1.07 | 13.66 | 269.90 | 5.76 | 343.54 | 0.3458 | 859.0 | 659.9 | |
| 0.00 | 0.88 | 0.00 | 0.46 | 13.08 | 269.45 | 5.31 | 344.29 | 0.3346 | 948.0 | 890.9 | |
| 0.00 | 1.50 | 0.00 | 0.81 | 17.78 | 268.73 | 4.59 | 349.15 | 0.4064 | 708.0 | 560.9 | |
| 1.15 | 2.74 | 0.61 | 1.45 | 14.60 | 268.03 | 3.89 | 349.27 | 0.3537 | 1016.4 | 831.3 | |
| 0.00 | 0.44 | 0.00 | 0.23 | 11.65 | 267.54 | 3.41 | 348.92 | 0.3041 | 780.0 | 715.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
