SDO HMI 2014-04-14 22:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.11 | 100.60 | 14.63 | 52.36 | -9.58 | 242.81 | -17.47 | 103.93 | 0.3066 | 186.8 | 173.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-14 22:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.41 | 0.00 | 0.72 | -12.28 | 248.50 | -11.77 | 120.51 | 0.2325 | 891.0 | 693.9 | |
| 0.00 | 1.33 | 0.00 | 0.68 | -11.51 | 248.06 | -12.21 | 116.73 | 0.2331 | 844.0 | 645.9 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -9.83 | 245.81 | -14.46 | 107.16 | 0.2586 | 907.0 | 684.3 | |
| 0.00 | 1.33 | 0.00 | 0.68 | -9.37 | 245.46 | -14.82 | 105.11 | 0.2625 | 830.0 | 581.5 | |
| 0.00 | 1.33 | 0.00 | 0.68 | -5.73 | 244.49 | -15.78 | 91.09 | 0.2718 | 789.0 | 658.8 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -10.06 | 244.28 | -15.99 | 106.57 | 0.2842 | 858.0 | 751.1 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -10.08 | 243.81 | -16.47 | 106.22 | 0.2919 | 966.0 | 842.7 | |
| 0.00 | 3.98 | 0.00 | 2.07 | -9.72 | 243.15 | -17.12 | 104.57 | 0.3011 | -650.0 | -777.4 | |
| 12.29 | 22.80 | 6.38 | 11.83 | -8.27 | 243.00 | -17.27 | 99.70 | 0.2993 | 1077.0 | 689.4 | |
| 0.00 | 0.80 | 0.00 | 0.41 | -9.90 | 242.86 | -17.41 | 104.92 | 0.3065 | -876.0 | -704.2 | |
| 0.35 | 2.30 | 0.18 | 1.20 | -10.20 | 242.81 | -17.46 | 105.84 | 0.3084 | -788.2 | -453.0 | |
| 0.71 | 4.24 | 0.37 | 2.21 | -9.38 | 242.82 | -17.45 | 103.24 | 0.3053 | -1125.4 | -828.7 | |
| 12.29 | 54.80 | 6.41 | 28.61 | -9.91 | 242.38 | -17.90 | 104.64 | 0.3142 | -1025.5 | 132.2 | |
| 2.47 | -13.00 | 1.29 | -13.00 | -10.17 | 242.07 | -18.20 | 105.25 | 0.3200 | 1044.1 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.60 | -10.19 | 241.68 | -18.59 | 105.04 | 0.3263 | 778.0 | 614.8 | |
| 0.00 | 1.68 | 0.00 | 0.89 | -12.54 | 240.28 | -19.99 | 110.64 | 0.3582 | 651.0 | 447.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
