SDO HMI 2014-04-15 03:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 58.46 | 386.36 | 31.89 | 210.69 | 11.79 | 275.10 | 17.59 | 314.94 | 0.4197 | -1032.7 | -399.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-15 03:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.97 | 0.00 | 0.52 | 7.55 | 276.64 | 19.12 | 304.41 | 0.3954 | -678.0 | -461.0 | |
| 58.46 | 374.94 | 31.89 | 204.55 | 11.74 | 275.24 | 17.73 | 314.60 | 0.4204 | -1350.6 | -423.0 | |
| 0.00 | 1.59 | 0.00 | 0.88 | 14.09 | 275.39 | 17.87 | 318.19 | 0.4483 | -631.0 | -439.7 | |
| 0.00 | 1.42 | 0.00 | 0.77 | 13.94 | 272.08 | 14.57 | 323.66 | 0.4136 | -812.0 | -588.0 | |
| 0.00 | 2.30 | 0.00 | 1.23 | 13.09 | 269.84 | 12.32 | 326.89 | 0.3821 | 1064.0 | 863.8 | |
| 0.00 | 1.06 | 0.00 | 0.57 | 14.73 | 268.97 | 11.46 | 330.96 | 0.3975 | 733.0 | 565.1 | |
| 0.00 | 1.42 | 0.00 | 0.75 | 13.81 | 267.38 | 9.87 | 333.34 | 0.3724 | 721.0 | 558.1 | |
| 0.00 | 1.42 | 0.00 | 0.77 | 16.12 | 267.11 | 9.60 | 336.55 | 0.4041 | 729.0 | 530.6 | |
| 0.00 | 1.24 | 0.00 | 0.65 | 11.95 | 266.25 | 8.73 | 333.73 | 0.3370 | 749.0 | 708.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
