SDO HMI 2014-04-15 09:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 61.48 | 382.63 | 34.25 | 212.91 | 11.87 | 274.96 | 20.73 | 310.37 | 0.4565 | -969.6 | -337.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-15 09:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 59.89 | 361.66 | 33.37 | 201.54 | 11.80 | 275.29 | 21.06 | 309.73 | 0.4593 | -1438.9 | -408.6 | |
| 1.59 | -1.00 | 0.88 | -1.00 | 11.22 | 275.11 | 20.88 | 308.98 | 0.4517 | -1286.5 | 999999 | |
| 0.00 | 8.58 | 0.00 | 4.67 | 12.88 | 270.52 | 16.30 | 318.84 | 0.4174 | 376.0 | 687.8 | |
| 0.00 | 1.95 | 0.00 | 1.06 | 13.09 | 270.09 | 15.86 | 319.94 | 0.4154 | 1110.0 | 937.8 | |
| 0.00 | 1.42 | 0.00 | 0.77 | 14.40 | 269.05 | 14.83 | 323.80 | 0.4215 | 712.0 | 611.7 | |
| 0.00 | 1.15 | 0.00 | 0.63 | 14.46 | 268.83 | 14.61 | 324.29 | 0.4202 | 760.0 | 637.2 | |
| 0.00 | 2.48 | 0.00 | 1.35 | 14.81 | 268.57 | 14.34 | 325.27 | 0.4222 | 820.0 | 682.0 | |
| 0.00 | 1.68 | 0.00 | 0.91 | 14.51 | 268.29 | 14.06 | 325.38 | 0.4159 | 1090.0 | 864.6 | |
| 0.00 | 1.15 | 0.00 | 0.62 | 13.75 | 267.38 | 13.16 | 326.08 | 0.3978 | 818.0 | 660.1 | |
| 0.00 | 1.06 | 0.00 | 0.56 | 12.02 | 266.47 | 12.24 | 325.38 | 0.3666 | 781.0 | 629.6 | |
| 0.00 | 1.50 | 0.00 | 0.80 | 11.89 | 266.05 | 11.83 | 326.09 | 0.3610 | 743.0 | 581.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
