SDO HMI 2014-04-16 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.72 | 86.18 | 12.36 | 77.63 | -13.17 | 181.39 | -56.90 | 102.18 | 0.8365 | 193.4 | 8.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-16 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.97 | 0.00 | 0.75 | -14.72 | 188.05 | -50.23 | 104.61 | 0.7705 | 414.0 | 349.7 | |
| 0.00 | 0.88 | 0.00 | 0.70 | -10.89 | 186.82 | -51.46 | 99.57 | 0.7812 | 595.0 | 556.7 | |
| 0.00 | 1.77 | 0.00 | 1.48 | -9.28 | 184.37 | -53.92 | 97.49 | 0.8067 | 70.0 | 116.0 | |
| 0.00 | 1.15 | 0.00 | 0.99 | -10.83 | 183.23 | -55.05 | 99.40 | 0.8182 | 363.0 | 319.2 | |
| 0.00 | 1.33 | 0.00 | 1.17 | -12.73 | 182.10 | -56.18 | 101.67 | 0.8297 | -278.0 | -370.5 | |
| 12.39 | 65.21 | 11.16 | 58.88 | -13.62 | 181.33 | -56.96 | 102.71 | 0.8373 | 674.6 | 85.0 | |
| 0.00 | 0.71 | 0.00 | 0.63 | -12.50 | 181.56 | -56.72 | 101.38 | 0.8347 | -507.0 | -439.8 | |
| 0.53 | 1.68 | 0.47 | 1.48 | -10.31 | 182.01 | -56.27 | 98.74 | 0.8300 | -446.5 | -396.5 | |
| 0.80 | 2.57 | 0.73 | 2.35 | -11.58 | 180.67 | -57.61 | 100.24 | 0.8428 | 381.6 | 297.6 | |
| 0.00 | 1.33 | 0.00 | 1.22 | -11.89 | 180.39 | -57.89 | 100.61 | 0.8454 | -389.0 | -350.7 | |
| 0.00 | 2.48 | 0.00 | 2.29 | -12.06 | 180.27 | -58.01 | 100.82 | 0.8465 | -638.0 | -538.4 | |
| 0.00 | 1.59 | 0.00 | 1.48 | -12.42 | 180.14 | -58.14 | 101.24 | 0.8477 | -640.0 | -559.1 | |
| 0.00 | 0.88 | 0.00 | 0.82 | -12.60 | 180.02 | -58.26 | 101.44 | 0.8489 | -513.0 | -465.6 | |
| 0.00 | 2.83 | 0.00 | 2.65 | -12.28 | 179.90 | -58.38 | 101.06 | 0.8499 | -469.0 | -348.6 | |
| 0.00 | 0.80 | 0.00 | 0.74 | -12.03 | 179.87 | -58.41 | 100.77 | 0.8501 | -253.0 | -267.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
