SDO HMI 2014-04-17 09:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.49 | 346.14 | 36.05 | 182.18 | -9.36 | 247.21 | 19.39 | 256.97 | 0.3375 | 272.9 | 197.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-17 09:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.33 | 0.00 | 0.71 | -6.88 | 249.55 | 21.73 | 265.02 | 0.3706 | 883.0 | 721.6 | |
| 39.77 | 215.66 | 21.14 | 114.58 | -9.10 | 248.95 | 21.13 | 258.82 | 0.3645 | 1385.2 | 454.1 | |
| 4.43 | -2.00 | 2.35 | -2.00 | -9.69 | 248.40 | 20.58 | 256.95 | 0.3573 | 1042.4 | 999999 | |
| 1.86 | 10.81 | 0.98 | 5.71 | -8.58 | 248.14 | 20.32 | 259.95 | 0.3503 | 1195.8 | 731.8 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -9.11 | 247.81 | 19.99 | 258.32 | 0.3463 | 267.0 | 201.1 | |
| 0.00 | 2.04 | 0.00 | 1.07 | -8.66 | 247.69 | 19.87 | 259.56 | 0.3432 | 891.0 | 652.0 | |
| 0.00 | 5.85 | 0.00 | 3.07 | -10.43 | 246.82 | 19.00 | 253.91 | 0.3348 | -592.0 | -709.3 | |
| 0.00 | 1.68 | 0.00 | 0.88 | -10.20 | 246.71 | 18.89 | 254.54 | 0.3321 | -788.0 | -657.0 | |
| 3.10 | 5.93 | 1.62 | 3.11 | -10.33 | 246.33 | 18.51 | 253.88 | 0.3266 | -1087.9 | -726.0 | |
| 0.00 | 1.15 | 0.00 | 0.60 | -8.52 | 246.14 | 18.32 | 259.30 | 0.3177 | 787.0 | 540.8 | |
| 0.71 | 2.66 | 0.37 | 1.39 | -10.34 | 245.94 | 18.13 | 253.57 | 0.3205 | 963.1 | 621.5 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -8.10 | 245.09 | 17.28 | 260.19 | 0.2997 | -688.0 | -551.5 | |
| 0.00 | 1.33 | 0.00 | 0.69 | -7.89 | 245.05 | 17.24 | 260.87 | 0.2986 | -791.0 | -563.1 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -9.07 | 244.92 | 17.10 | 256.88 | 0.2994 | 720.0 | 496.2 | |
| 0.00 | 2.13 | 0.00 | 1.10 | -8.80 | 244.78 | 16.96 | 257.69 | 0.2963 | 899.0 | 716.8 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -10.80 | 244.62 | 16.80 | 251.04 | 0.3016 | -744.0 | -617.5 | |
| 0.44 | 1.59 | 0.23 | 0.83 | -8.99 | 244.50 | 16.68 | 256.88 | 0.2924 | 1090.2 | 892.6 | |
| 0.00 | 1.51 | 0.00 | 0.78 | -10.77 | 244.46 | 16.64 | 250.97 | 0.2989 | -712.0 | -593.2 | |
| 0.00 | 3.10 | 0.00 | 1.61 | -10.47 | 244.41 | 16.59 | 251.90 | 0.2968 | -780.0 | -646.5 | |
| 0.00 | 2.04 | 0.00 | 1.06 | -11.74 | 244.33 | 16.51 | 247.74 | 0.3019 | -699.0 | -646.3 | |
| 0.00 | 2.66 | 0.00 | 1.38 | -10.84 | 244.21 | 16.39 | 250.51 | 0.2953 | -842.0 | -725.8 | |
| 3.19 | 4.69 | 1.65 | 2.42 | -8.46 | 244.06 | 16.24 | 258.44 | 0.2837 | 1080.1 | 817.6 | |
| 0.00 | 3.81 | 0.00 | 1.97 | -10.45 | 244.09 | 16.27 | 251.68 | 0.2916 | -948.0 | -866.1 | |
| 0.00 | 1.59 | 0.00 | 0.82 | -10.15 | 243.82 | 16.00 | 252.42 | 0.2860 | -898.0 | -699.1 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -10.79 | 243.60 | 15.78 | 250.04 | 0.2855 | -979.0 | -707.6 | |
| 0.00 | 2.57 | 0.00 | 1.32 | -9.22 | 243.46 | 15.64 | 255.32 | 0.2764 | -842.0 | -648.8 | |
| 0.89 | 50.66 | 0.46 | 26.08 | -9.59 | 243.41 | 15.60 | 254.00 | 0.2770 | -933.0 | -248.6 | |
| 0.80 | 3.63 | 0.41 | 1.87 | -11.29 | 243.18 | 15.36 | 247.92 | 0.2816 | -973.8 | -916.7 | |
| 9.48 | -27.00 | 4.88 | -27.00 | -9.69 | 243.07 | 15.25 | 253.34 | 0.2719 | -1079.3 | 999999 | |
| 0.89 | 2.13 | 0.46 | 1.10 | -10.74 | 243.06 | 15.24 | 249.62 | 0.2767 | -1026.4 | -923.7 | |
| 0.00 | 1.86 | 0.00 | 0.96 | -10.06 | 242.74 | 14.92 | 251.69 | 0.2682 | -993.0 | -689.6 | |
| 1.51 | -27.00 | 0.77 | -27.00 | -9.51 | 242.68 | 14.87 | 253.61 | 0.2649 | 1102.5 | 999999 | |
| 0.00 | 1.33 | 0.00 | 0.68 | -10.45 | 242.66 | 14.84 | 250.20 | 0.2690 | -903.0 | -738.7 | |
| 1.42 | 2.66 | 0.73 | 1.37 | -10.76 | 242.52 | 14.70 | 248.95 | 0.2683 | -1011.1 | -780.4 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -9.16 | 242.35 | 14.54 | 254.63 | 0.2581 | 920.0 | 821.9 | |
| 0.00 | 1.33 | 0.00 | 0.68 | -10.34 | 242.37 | 14.55 | 250.29 | 0.2638 | -666.0 | -449.9 | |
| 0.00 | 1.33 | 0.00 | 0.67 | -8.65 | 239.18 | 11.36 | 253.40 | 0.2041 | -946.0 | -695.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
