SDO HMI 2014-04-17 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 131.97 | 712.18 | 66.60 | 360.18 | -15.91 | 223.76 | -0.21 | 180.56 | 0.1975 | 269.4 | 238.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-17 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.15 | 0.00 | 0.58 | -15.62 | 229.53 | 5.56 | 207.70 | 0.2015 | -657.0 | -479.3 | |
| 0.00 | 1.33 | 0.00 | 0.67 | -15.75 | 228.66 | 4.68 | 203.61 | 0.1970 | 950.0 | 795.9 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -14.77 | 228.51 | 4.54 | 205.14 | 0.1808 | 978.0 | 862.3 | |
| 0.00 | 2.66 | 0.00 | 1.32 | -10.01 | 228.19 | 4.21 | 221.96 | 0.1087 | 859.0 | 767.8 | |
| 0.00 | 0.89 | 0.00 | 0.45 | -14.65 | 228.26 | 4.28 | 204.20 | 0.1771 | 880.0 | 680.0 | |
| 0.00 | 1.15 | 0.00 | 0.57 | -9.20 | 228.12 | 4.14 | 227.09 | 0.0979 | 928.0 | 712.7 | |
| 0.00 | 0.89 | 0.00 | 0.44 | -9.65 | 228.09 | 4.12 | 223.66 | 0.1030 | 789.0 | 669.8 | |
| 2.92 | 350.16 | 1.48 | 177.01 | -16.36 | 228.17 | 4.19 | 200.24 | 0.2037 | 788.8 | 435.0 | |
| 0.00 | 2.04 | 0.00 | 1.02 | -10.77 | 227.71 | 3.73 | 214.34 | 0.1139 | 859.0 | 577.0 | |
| 4.96 | -8.00 | 2.51 | -8.00 | -16.92 | 227.71 | 3.73 | 197.32 | 0.2101 | 1048.9 | 999999 | |
| 10.71 | -8.00 | 5.42 | -8.00 | -16.67 | 227.67 | 3.69 | 197.53 | 0.2059 | 1274.4 | 999999 | |
| 7.44 | -8.00 | 3.76 | -8.00 | -16.46 | 227.60 | 3.63 | 197.56 | 0.2021 | 1433.8 | 999999 | |
| 0.00 | 1.77 | 0.00 | 0.89 | -14.81 | 227.48 | 3.51 | 199.90 | 0.1746 | 984.0 | 716.5 | |
| 38.41 | -8.00 | 19.39 | -8.00 | -16.00 | 227.47 | 3.49 | 197.67 | 0.1939 | 1562.3 | 999999 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -14.47 | 227.38 | 3.41 | 200.06 | 0.1686 | -564.0 | -487.2 | |
| 0.00 | 3.45 | 0.00 | 1.73 | -14.14 | 226.57 | 2.60 | 196.14 | 0.1588 | -1002.0 | -899.0 | |
| 0.00 | 1.06 | 0.00 | 0.53 | -11.23 | 226.36 | 2.39 | 201.93 | 0.1099 | 884.0 | 738.7 | |
| 0.00 | 2.57 | 0.00 | 1.29 | -13.90 | 225.92 | 1.94 | 192.57 | 0.1520 | -1049.0 | -775.2 | |
| 0.00 | 1.95 | 0.00 | 0.97 | -13.17 | 225.88 | 1.91 | 193.50 | 0.1395 | -929.0 | -723.9 | |
| 0.00 | 12.75 | 0.00 | 6.35 | -11.32 | 225.81 | 1.84 | 196.95 | 0.1082 | 814.0 | 948.9 | |
| 0.00 | 1.24 | 0.00 | 0.61 | -6.56 | 225.64 | 1.67 | 235.18 | 0.0353 | 967.0 | 791.9 | |
| 0.62 | 1.86 | 0.31 | 0.92 | -6.38 | 225.58 | 1.60 | 238.69 | 0.0327 | 1171.9 | 959.7 | |
| 0.00 | 1.33 | 0.00 | 0.66 | -5.96 | 225.55 | 1.57 | 250.67 | 0.0291 | 888.0 | 707.6 | |
| 0.00 | 1.24 | 0.00 | 0.63 | -19.05 | 225.30 | 1.32 | 185.28 | 0.2379 | -720.0 | -578.9 | |
| 0.00 | 1.15 | 0.00 | 0.57 | -10.63 | 225.22 | 1.25 | 193.27 | 0.0939 | 987.0 | 744.9 | |
| 0.00 | 1.77 | 0.00 | 0.88 | -11.84 | 225.14 | 1.16 | 190.05 | 0.1142 | 806.0 | 507.5 | |
| 0.00 | 2.66 | 0.00 | 1.32 | -11.59 | 225.04 | 1.07 | 189.63 | 0.1098 | 816.0 | 806.3 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -11.29 | 224.67 | 0.70 | 186.67 | 0.1036 | 811.0 | 673.1 | |
| 0.00 | 1.24 | 0.00 | 0.61 | -7.82 | 224.61 | 0.64 | 194.64 | 0.0437 | -942.0 | -769.6 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -14.54 | 224.09 | 0.11 | 180.70 | 0.1594 | 881.0 | 644.1 | |
| 1.33 | 11.77 | 0.67 | 5.90 | -14.29 | 223.65 | -0.32 | 177.99 | 0.1552 | 1257.0 | 937.7 | |
| 0.00 | 1.15 | 0.00 | 0.58 | -14.11 | 223.47 | -0.51 | 176.76 | 0.1522 | 888.0 | 780.1 | |
| 15.67 | 25.93 | 7.88 | 13.05 | -15.33 | 223.34 | -0.63 | 176.45 | 0.1734 | 1163.6 | 738.6 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -10.78 | 223.17 | -0.80 | 171.65 | 0.0950 | 859.0 | 681.6 | |
| 0.00 | 2.12 | 0.00 | 1.07 | -14.29 | 223.13 | -0.85 | 174.70 | 0.1558 | 1074.0 | 884.0 | |
| 0.00 | 1.59 | 0.00 | 0.80 | -14.05 | 223.13 | -0.85 | 174.55 | 0.1516 | 894.0 | 787.4 | |
| 1.59 | -33.00 | 0.80 | -33.00 | -15.48 | 223.06 | -0.92 | 174.97 | 0.1764 | 981.8 | 999999 | |
| 0.00 | 1.50 | 0.00 | 0.76 | -16.64 | 222.80 | -1.17 | 174.25 | 0.1967 | 923.0 | 763.4 | |
| 0.00 | 1.50 | 0.00 | 0.75 | -14.44 | 222.66 | -1.31 | 171.95 | 0.1593 | 1053.0 | 887.1 | |
| 0.00 | 1.95 | 0.00 | 0.98 | -14.38 | 222.44 | -1.53 | 170.58 | 0.1588 | 1218.0 | 950.4 | |
| 0.00 | 1.15 | 0.00 | 0.58 | -15.42 | 222.06 | -1.91 | 169.50 | 0.1776 | 954.0 | 770.4 | |
| 0.00 | 1.95 | 0.00 | 0.98 | -14.35 | 221.92 | -2.06 | 167.38 | 0.1600 | 1221.0 | 1016.8 | |
| 1.68 | 8.41 | 0.85 | 4.23 | -15.05 | 221.88 | -2.10 | 168.09 | 0.1720 | 1160.9 | 845.7 | |
| 0.00 | 2.48 | 0.00 | 1.25 | -15.57 | 221.71 | -2.26 | 167.85 | 0.1813 | 691.0 | 421.2 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -14.62 | 221.66 | -2.31 | 166.31 | 0.1656 | 1000.0 | 764.0 | |
| 0.80 | 2.12 | 0.40 | 1.07 | -14.20 | 221.64 | -2.34 | 165.50 | 0.1586 | 1012.8 | 800.1 | |
| 0.00 | 1.24 | 0.00 | 0.63 | -17.90 | 221.37 | -2.61 | 168.69 | 0.2216 | 84.0 | 92.5 | |
| 0.00 | 2.21 | 0.00 | 1.11 | -14.13 | 221.27 | -2.71 | 163.20 | 0.1592 | 977.0 | 796.3 | |
| 1.86 | 4.34 | 0.93 | 2.17 | -13.89 | 221.11 | -2.86 | 161.82 | 0.1560 | 1056.6 | 876.3 | |
| 0.00 | 2.12 | 0.00 | 1.08 | -16.88 | 220.94 | -3.03 | 165.73 | 0.2063 | 1042.0 | 864.5 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -19.07 | 220.84 | -3.14 | 167.66 | 0.2429 | 660.0 | 510.2 | |
| 0.00 | 2.30 | 0.00 | 1.16 | -16.67 | 220.70 | -3.28 | 164.33 | 0.2038 | 934.0 | 752.7 | |
| 0.00 | 1.86 | 0.00 | 0.94 | -17.22 | 220.65 | -3.32 | 164.88 | 0.2131 | 631.0 | 447.0 | |
| 0.00 | 1.06 | 0.00 | 0.54 | -16.69 | 220.41 | -3.56 | 163.09 | 0.2056 | 861.0 | 783.0 | |
| 0.00 | 1.15 | 0.00 | 0.58 | -16.33 | 220.39 | -3.59 | 162.42 | 0.1997 | 1134.0 | 961.5 | |
| 0.00 | 3.45 | 0.00 | 1.75 | -17.00 | 220.31 | -3.66 | 163.10 | 0.2111 | 619.0 | 528.3 | |
| 0.00 | 1.95 | 0.00 | 0.99 | -16.54 | 220.29 | -3.69 | 162.31 | 0.2037 | 1207.0 | 971.2 | |
| 7.52 | 27.35 | 3.81 | 13.85 | -16.44 | 219.63 | -4.34 | 159.24 | 0.2059 | 986.2 | 773.4 | |
| 0.00 | 1.24 | 0.00 | 0.63 | -18.41 | 219.45 | -4.52 | 161.63 | 0.2384 | -839.0 | -633.8 | |
| 0.00 | 25.49 | 0.00 | 12.93 | -16.96 | 219.18 | -4.80 | 158.25 | 0.2169 | -320.0 | -353.8 | |
| 3.98 | 33.90 | 2.02 | 17.17 | -16.19 | 219.13 | -4.84 | 156.61 | 0.2051 | 1162.5 | -129.3 | |
| 0.00 | 0.80 | 0.00 | 0.40 | -15.28 | 219.00 | -4.97 | 154.02 | 0.1918 | -488.0 | -351.0 | |
| 0.00 | 1.15 | 0.00 | 0.59 | -18.13 | 218.76 | -5.21 | 158.62 | 0.2378 | -789.0 | -758.8 | |
| 19.56 | 57.00 | 9.85 | 28.74 | -14.54 | 218.83 | -5.14 | 151.38 | 0.1820 | -1141.6 | -424.3 | |
| 0.62 | 2.83 | 0.31 | 1.44 | -17.29 | 218.76 | -5.22 | 157.17 | 0.2248 | -958.7 | -734.0 | |
| 0.00 | 0.89 | 0.00 | 0.44 | -8.31 | 218.95 | -5.02 | 120.44 | 0.1010 | 802.0 | 632.8 | |
| 0.00 | 0.97 | 0.00 | 0.49 | -15.61 | 218.74 | -5.23 | 153.66 | 0.1989 | 91.0 | 122.6 | |
| 0.00 | 0.89 | 0.00 | 0.45 | -18.25 | 218.60 | -5.37 | 158.21 | 0.2408 | -919.0 | -772.8 | |
| 0.00 | 4.34 | 0.00 | 2.20 | -16.68 | 218.62 | -5.36 | 155.45 | 0.2162 | -902.0 | -799.9 | |
| 3.98 | -64.00 | 2.01 | -64.00 | -14.90 | 218.51 | -5.47 | 150.90 | 0.1901 | -1028.5 | 999999 | |
| 1.15 | -61.00 | 0.58 | -61.00 | -16.06 | 218.29 | -5.69 | 152.80 | 0.2093 | -968.1 | 999999 | |
| 6.20 | -64.00 | 3.13 | -64.00 | -14.90 | 218.26 | -5.72 | 149.80 | 0.1922 | -894.8 | 999999 | |
| 0.00 | 2.92 | 0.00 | 1.48 | -15.42 | 218.24 | -5.73 | 151.09 | 0.2000 | 559.0 | 343.9 | |
| 0.00 | 2.66 | 0.00 | 1.35 | -16.52 | 218.05 | -5.92 | 152.89 | 0.2180 | -1122.0 | -916.0 | |
| 0.00 | 1.42 | 0.00 | 0.72 | -17.32 | 218.00 | -5.98 | 154.32 | 0.2305 | -934.0 | -784.2 | |
| 0.97 | 1.77 | 0.49 | 0.90 | -16.30 | 217.84 | -6.13 | 151.57 | 0.2164 | -1089.2 | -870.2 | |
| 0.00 | 1.15 | 0.00 | 0.58 | -15.94 | 217.79 | -6.19 | 150.51 | 0.2114 | -1066.0 | -853.2 | |
| 0.00 | 0.89 | 0.00 | 0.45 | -17.81 | 217.69 | -6.28 | 154.17 | 0.2402 | -978.0 | -836.2 | |
| 0.00 | 1.33 | 0.00 | 0.66 | -7.27 | 217.72 | -6.26 | 106.99 | 0.1136 | 926.0 | 724.0 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -16.82 | 217.44 | -6.53 | 151.24 | 0.2273 | -984.0 | -831.5 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -13.61 | 217.33 | -6.65 | 141.86 | 0.1830 | -853.0 | -785.4 | |
| 0.00 | 1.24 | 0.00 | 0.62 | -13.73 | 217.08 | -6.90 | 141.25 | 0.1872 | -907.0 | -733.8 | |
| 0.00 | 1.77 | 0.00 | 0.91 | -19.46 | 216.54 | -7.44 | 153.38 | 0.2736 | -847.0 | -694.0 | |
| 0.00 | 2.57 | 0.00 | 1.32 | -18.84 | 216.47 | -7.51 | 152.05 | 0.2650 | -1006.0 | -854.7 | |
| 0.00 | 2.12 | 0.00 | 1.09 | -19.21 | 216.29 | -7.68 | 152.19 | 0.2718 | -862.0 | -590.1 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -18.65 | 216.19 | -7.79 | 150.82 | 0.2645 | -891.0 | -708.3 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -18.37 | 216.20 | -7.77 | 150.32 | 0.2603 | -883.0 | -706.2 | |
| 0.00 | 1.42 | 0.00 | 0.73 | -20.79 | 216.05 | -7.93 | 154.15 | 0.2970 | -721.0 | -540.3 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -19.30 | 216.03 | -7.95 | 151.56 | 0.2752 | -871.0 | -704.0 | |
| 0.00 | 1.33 | 0.00 | 0.68 | -17.57 | 215.92 | -8.05 | 147.73 | 0.2513 | -879.0 | -719.5 | |
| 0.00 | 1.06 | 0.00 | 0.54 | -17.26 | 215.90 | -8.07 | 146.97 | 0.2471 | -923.0 | -733.7 | |
| 0.00 | 1.50 | 0.00 | 0.78 | -20.26 | 215.49 | -8.48 | 151.72 | 0.2933 | -992.0 | -858.9 | |
| 0.00 | 3.89 | 0.00 | 1.99 | -17.20 | 215.62 | -8.35 | 145.92 | 0.2488 | -1051.0 | -721.7 | |
| 0.00 | 2.04 | 0.00 | 1.06 | -21.31 | 215.27 | -8.71 | 152.86 | 0.3104 | -762.0 | -530.6 | |
| 0.00 | 3.98 | 0.00 | 2.06 | -20.00 | 215.12 | -8.86 | 150.24 | 0.2927 | -889.0 | -687.4 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -20.50 | 215.06 | -8.92 | 150.95 | 0.3003 | -724.0 | -625.2 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -16.97 | 215.15 | -8.82 | 143.95 | 0.2504 | -863.0 | -712.1 | |
| 0.00 | 1.15 | 0.00 | 0.60 | -20.95 | 214.08 | -9.89 | 149.21 | 0.3148 | -838.0 | -705.7 | |
| 0.00 | 1.59 | 0.00 | 0.83 | -20.57 | 213.95 | -10.03 | 148.20 | 0.3107 | -697.0 | -602.0 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -20.33 | 213.93 | -10.04 | 147.70 | 0.3074 | -981.0 | -779.9 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -19.51 | 213.50 | -10.48 | 145.03 | 0.3004 | -582.0 | -529.4 | |
| 0.00 | 1.50 | 0.00 | 0.78 | -19.32 | 213.38 | -10.60 | 144.35 | 0.2990 | -972.0 | -793.0 | |
| 0.00 | 1.77 | 0.00 | 0.92 | -19.13 | 212.91 | -11.07 | 142.77 | 0.3012 | -726.0 | -657.2 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -18.60 | 212.65 | -11.32 | 141.00 | 0.2970 | -898.0 | -618.1 | |
| 0.00 | 1.86 | 0.00 | 0.98 | -21.25 | 211.66 | -12.31 | 144.14 | 0.3408 | -896.0 | -765.7 | |
| 0.00 | 1.86 | 0.00 | 0.96 | -18.02 | 211.85 | -12.12 | 137.81 | 0.2987 | -927.0 | -747.8 | |
| 0.00 | 1.68 | 0.00 | 0.87 | -17.73 | 211.00 | -12.98 | 135.23 | 0.3051 | -886.0 | -750.4 | |
| 0.00 | 3.63 | 0.00 | 1.89 | -18.09 | 210.81 | -13.17 | 135.70 | 0.3114 | -755.0 | -711.5 | |
| 0.00 | 2.30 | 0.00 | 1.20 | -18.37 | 210.72 | -13.25 | 136.17 | 0.3156 | -702.0 | -579.9 | |
| 0.00 | 0.80 | 0.00 | 0.43 | -22.69 | 209.79 | -14.19 | 142.96 | 0.3770 | -773.0 | -579.3 | |
| 0.00 | 1.42 | 0.00 | 0.76 | -22.12 | 209.65 | -14.33 | 141.69 | 0.3714 | -743.0 | -665.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
