SDO HMI 2014-04-17 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 54.79 | 317.32 | 29.66 | 171.37 | -9.38 | 247.17 | 23.20 | 258.60 | 0.3978 | 344.1 | 188.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-17 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.06 | 0.00 | 0.59 | -6.51 | 251.80 | 27.82 | 266.29 | 0.4666 | 640.0 | 493.2 | |
| 0.00 | 2.39 | 0.00 | 1.32 | -7.23 | 250.48 | 26.50 | 264.63 | 0.4465 | 599.0 | 470.1 | |
| 0.00 | 1.95 | 0.00 | 1.07 | -6.78 | 249.67 | 25.70 | 265.59 | 0.4337 | 755.0 | 615.2 | |
| 36.91 | 178.88 | 20.20 | 97.91 | -9.07 | 249.08 | 25.11 | 260.18 | 0.4270 | 1327.1 | 428.2 | |
| 0.27 | -4.00 | 0.14 | -4.00 | -9.06 | 248.54 | 24.57 | 260.05 | 0.4186 | 1269.7 | 999999 | |
| 1.59 | 9.47 | 0.87 | 5.15 | -9.67 | 248.35 | 24.38 | 258.54 | 0.4169 | 983.6 | 657.1 | |
| 0.00 | 5.49 | 0.00 | 2.98 | -8.53 | 248.24 | 24.26 | 261.25 | 0.4129 | 784.0 | 793.6 | |
| 0.00 | 1.50 | 0.00 | 0.81 | -8.57 | 247.77 | 23.80 | 261.02 | 0.4057 | 856.0 | 746.9 | |
| 0.00 | 1.77 | 0.00 | 0.95 | -10.35 | 246.94 | 22.96 | 256.31 | 0.3967 | -709.0 | -637.6 | |
| 0.00 | 2.83 | 0.00 | 1.53 | -9.96 | 246.87 | 22.90 | 257.25 | 0.3946 | -569.0 | -518.7 | |
| 0.00 | 2.04 | 0.00 | 1.10 | -10.21 | 246.76 | 22.78 | 256.59 | 0.3935 | -872.0 | -768.9 | |
| 1.50 | 9.03 | 0.81 | 4.85 | -10.25 | 246.43 | 22.46 | 256.33 | 0.3885 | -1079.7 | -288.5 | |
| 1.24 | -12.00 | 0.66 | -12.00 | -10.32 | 246.14 | 22.16 | 256.01 | 0.3841 | 741.1 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -9.00 | 245.03 | 21.06 | 259.03 | 0.3631 | 837.0 | 676.2 | |
| 0.00 | 0.80 | 0.00 | 0.42 | -9.10 | 244.78 | 20.80 | 258.65 | 0.3592 | 872.0 | 729.3 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -9.04 | 244.64 | 20.67 | 258.75 | 0.3569 | 1025.0 | 852.9 | |
| 0.00 | 8.23 | 0.00 | 4.37 | -10.52 | 244.57 | 20.60 | 254.64 | 0.3603 | -768.0 | -698.2 | |
| 1.95 | 3.19 | 1.03 | 1.68 | -8.48 | 244.16 | 20.18 | 260.14 | 0.3479 | 1032.1 | 788.1 | |
| 0.00 | 0.71 | 0.00 | 0.38 | -11.86 | 244.38 | 20.40 | 250.90 | 0.3626 | -782.0 | -640.0 | |
| 0.71 | 3.36 | 0.37 | 1.78 | -10.50 | 244.25 | 20.27 | 254.50 | 0.3551 | -968.0 | -807.9 | |
| 0.00 | 1.68 | 0.00 | 0.89 | -10.09 | 243.93 | 19.95 | 255.46 | 0.3486 | -809.0 | -724.9 | |
| 0.00 | 2.57 | 0.00 | 1.35 | -9.49 | 243.79 | 19.82 | 257.09 | 0.3446 | -617.0 | -440.6 | |
| 0.00 | 6.02 | 0.00 | 3.18 | -10.40 | 243.82 | 19.84 | 254.53 | 0.3479 | -733.0 | -691.3 | |
| 0.71 | 7.08 | 0.37 | 3.73 | -10.01 | 243.60 | 19.62 | 255.49 | 0.3431 | -1072.5 | -797.9 | |
| 0.00 | 0.62 | 0.00 | 0.33 | -11.26 | 243.29 | 19.31 | 251.73 | 0.3431 | -802.0 | -614.4 | |
| 7.61 | 53.37 | 4.00 | 28.02 | -9.81 | 243.16 | 19.19 | 255.81 | 0.3355 | -1081.3 | -9.7 | |
| 0.44 | 4.16 | 0.23 | 2.19 | -10.99 | 243.17 | 19.20 | 252.41 | 0.3401 | -1070.2 | -772.4 | |
| 0.62 | 1.95 | 0.33 | 1.02 | -10.63 | 243.12 | 19.14 | 253.40 | 0.3378 | -1079.9 | -879.2 | |
| 0.53 | -26.00 | 0.28 | -26.00 | -9.88 | 242.72 | 18.74 | 255.32 | 0.3286 | -705.3 | 999999 | |
| 0.71 | 1.68 | 0.37 | 0.88 | -10.76 | 242.67 | 18.70 | 252.69 | 0.3313 | -928.2 | -788.8 | |
| 0.00 | 2.04 | 0.00 | 1.07 | -9.17 | 242.51 | 18.54 | 257.37 | 0.3231 | 813.0 | 689.4 | |
| 0.00 | 1.24 | 0.00 | 0.65 | -10.45 | 241.91 | 17.94 | 253.04 | 0.3180 | 892.0 | 641.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
