SDO HMI 2014-04-17 19:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 65.86 | 342.20 | 66.84 | 344.07 | 18.64 | 166.05 | -56.27 | 64.93 | 0.8706 | -216.5 | -191.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-17 19:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.76 | 248.98 | 8.20 | 236.64 | 18.35 | 168.63 | -53.69 | 64.40 | 0.8502 | -993.1 | -297.6 | |
| 17.26 | -1.00 | 16.36 | -1.00 | 18.93 | 168.30 | -54.01 | 63.87 | 0.8545 | -815.1 | 999999 | |
| 9.21 | -1.00 | 8.77 | -1.00 | 18.41 | 167.89 | -54.42 | 64.60 | 0.8564 | -672.6 | 999999 | |
| 0.00 | 1.06 | 0.00 | 1.05 | 19.90 | 166.87 | -55.44 | 63.32 | 0.8687 | 289.0 | 292.9 | |
| 7.70 | -1.00 | 7.45 | -1.00 | 18.36 | 167.31 | -55.01 | 64.86 | 0.8609 | -426.4 | 999999 | |
| 3.81 | -1.00 | 3.70 | -1.00 | 18.22 | 167.04 | -55.28 | 65.11 | 0.8627 | -462.9 | 999999 | |
| 0.00 | 1.42 | 0.00 | 1.42 | 19.14 | 166.19 | -56.13 | 64.39 | 0.8719 | -307.0 | -210.5 | |
| 0.00 | 1.33 | 0.00 | 1.31 | 17.91 | 166.51 | -55.80 | 65.63 | 0.8660 | -313.0 | -160.1 | |
| 0.00 | 4.25 | 0.00 | 4.19 | 17.69 | 166.39 | -55.93 | 65.91 | 0.8664 | 45.0 | -28.5 | |
| 0.00 | 0.71 | 0.00 | 0.72 | 17.46 | 165.23 | -57.08 | 66.53 | 0.8750 | -297.0 | -232.9 | |
| 0.00 | 2.92 | 0.00 | 2.99 | 17.77 | 165.02 | -57.30 | 66.26 | 0.8773 | -321.0 | -171.2 | |
| 0.00 | 0.97 | 0.00 | 1.02 | 17.59 | 164.10 | -58.22 | 66.75 | 0.8839 | 374.0 | 342.2 | |
| 0.00 | 0.89 | 0.00 | 0.92 | 16.60 | 164.35 | -57.97 | 67.75 | 0.8797 | 512.0 | 490.2 | |
| 0.00 | 0.71 | 0.00 | 0.74 | 16.89 | 163.97 | -58.35 | 67.55 | 0.8833 | 472.0 | 428.4 | |
| 0.00 | 1.50 | 0.00 | 1.74 | 20.18 | 161.90 | -60.41 | 64.62 | 0.9052 | 351.0 | 302.9 | |
| 0.00 | 0.89 | 0.00 | 1.02 | 19.80 | 161.75 | -60.56 | 65.07 | 0.9054 | 451.0 | 388.1 | |
| 0.00 | 0.27 | 0.00 | 0.30 | 19.53 | 161.93 | -60.39 | 65.31 | 0.9036 | 560.0 | 562.3 | |
| 0.00 | 1.50 | 0.00 | 1.74 | 19.38 | 161.69 | -60.62 | 65.53 | 0.9049 | 533.0 | 478.2 | |
| 0.00 | 2.48 | 0.00 | 2.81 | 18.68 | 161.93 | -60.39 | 66.21 | 0.9018 | 532.0 | 392.5 | |
| 2.83 | 6.11 | 3.18 | 6.83 | 18.02 | 162.12 | -60.19 | 66.87 | 0.8991 | 486.1 | 348.6 | |
| 5.49 | 62.58 | 6.38 | 74.42 | 19.12 | 161.40 | -60.92 | 65.90 | 0.9063 | 607.1 | -27.8 | |
| 0.00 | 2.21 | 0.00 | 2.63 | 19.68 | 160.97 | -61.34 | 65.43 | 0.9103 | 324.0 | 192.8 | |
| 4.87 | -21.00 | 5.76 | -21.00 | 19.13 | 160.86 | -61.46 | 66.04 | 0.9100 | 352.9 | 999999 | |
| 0.00 | 1.42 | 0.00 | 1.58 | 16.83 | 162.01 | -60.31 | 68.17 | 0.8975 | 486.0 | 395.9 | |
| 5.93 | -21.00 | 7.04 | -21.00 | 18.76 | 160.62 | -61.70 | 66.50 | 0.9108 | 452.6 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
