SDO HMI 2014-04-18 03:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.47 | 152.91 | 17.59 | 113.45 | 11.91 | 262.87 | 44.97 | 291.52 | 0.7444 | -479.9 | -277.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-18 03:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.78 | 143.35 | 8.86 | 107.49 | 11.94 | 263.79 | 45.89 | 291.02 | 0.7548 | -775.4 | -311.4 | |
| 11.69 | -1.00 | 8.73 | -1.00 | 11.61 | 263.45 | 45.55 | 290.73 | 0.7500 | -1065.8 | 999999 | |
| 0.00 | 1.95 | 0.00 | 1.39 | 17.35 | 258.23 | 40.33 | 300.58 | 0.7200 | -624.0 | -439.4 | |
| 0.00 | 0.71 | 0.00 | 0.50 | 17.34 | 258.02 | 40.12 | 300.69 | 0.7177 | -551.0 | -508.1 | |
| 0.00 | 1.06 | 0.00 | 0.63 | 13.03 | 245.88 | 27.98 | 303.73 | 0.5517 | 581.0 | 486.7 | |
| 0.00 | 1.06 | 0.00 | 0.63 | 13.02 | 245.70 | 27.80 | 303.89 | 0.5495 | 666.0 | 649.5 | |
| 0.00 | 0.71 | 0.00 | 0.42 | 12.83 | 245.54 | 27.64 | 303.73 | 0.5460 | 703.0 | 523.0 | |
| 0.00 | 1.24 | 0.00 | 0.73 | 12.88 | 245.19 | 27.29 | 304.14 | 0.5422 | 769.0 | 578.5 | |
| 0.00 | 0.97 | 0.00 | 0.57 | 13.21 | 244.89 | 26.99 | 304.96 | 0.5412 | 564.0 | 468.6 | |
| 0.00 | 1.24 | 0.00 | 0.73 | 12.69 | 244.65 | 26.75 | 304.38 | 0.5342 | 745.0 | 626.4 | |
| 0.00 | 0.62 | 0.00 | 0.36 | 13.14 | 244.70 | 26.81 | 305.03 | 0.5384 | 560.0 | 568.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
