SDO HMI 2014-04-18 09:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.59 | 224.62 | 40.63 | 133.43 | -12.64 | 181.62 | -32.99 | 104.89 | 0.5521 | 437.2 | 21.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-18 09:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.33 | 0.00 | 0.74 | -13.92 | 188.69 | -25.92 | 110.45 | 0.4547 | 728.0 | 627.0 | |
| 0.00 | 0.80 | 0.00 | 0.45 | -13.16 | 187.33 | -27.29 | 108.12 | 0.4716 | 615.0 | 439.7 | |
| 0.00 | 1.77 | 0.00 | 1.00 | -10.21 | 186.47 | -28.14 | 101.64 | 0.4759 | 680.0 | 537.1 | |
| 0.00 | 1.24 | 0.00 | 0.70 | -7.56 | 186.07 | -28.54 | 96.02 | 0.4782 | 721.0 | 653.4 | |
| 0.00 | 1.15 | 0.00 | 0.66 | -8.60 | 184.98 | -29.63 | 98.01 | 0.4957 | 791.0 | 700.6 | |
| 0.00 | 1.06 | 0.00 | 0.61 | -8.87 | 184.95 | -29.66 | 98.55 | 0.4964 | 859.0 | 672.4 | |
| 1.42 | 5.58 | 0.81 | 3.19 | -8.44 | 184.78 | -29.83 | 97.66 | 0.4985 | 825.1 | 567.4 | |
| 0.00 | 1.15 | 0.00 | 0.66 | -11.24 | 183.96 | -30.65 | 103.02 | 0.5152 | 755.0 | 613.2 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -10.87 | 183.83 | -30.78 | 102.26 | 0.5164 | 728.0 | 582.8 | |
| 24.46 | 37.75 | 14.23 | 21.98 | -12.25 | 183.33 | -31.28 | 104.73 | 0.5267 | 987.9 | 502.8 | |
| 0.53 | -10.00 | 0.31 | -10.00 | -12.61 | 183.21 | -31.40 | 105.37 | 0.5294 | 555.3 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -8.96 | 183.64 | -30.97 | 98.52 | 0.5161 | 602.0 | 450.2 | |
| 0.00 | 1.24 | 0.00 | 0.72 | -10.70 | 183.42 | -31.19 | 101.83 | 0.5221 | 754.0 | 610.4 | |
| 0.00 | 1.77 | 0.00 | 1.03 | -8.61 | 183.39 | -31.23 | 97.82 | 0.5194 | -892.0 | -687.4 | |
| 0.00 | 1.24 | 0.00 | 0.72 | -11.17 | 183.07 | -31.54 | 102.64 | 0.5280 | 579.0 | 435.4 | |
| 0.00 | 2.75 | 0.00 | 1.62 | -12.19 | 182.21 | -32.40 | 104.29 | 0.5426 | 589.0 | 535.9 | |
| 22.15 | 92.60 | 13.19 | 55.22 | -13.37 | 181.41 | -33.20 | 106.17 | 0.5568 | 1140.6 | 152.3 | |
| 0.00 | 1.06 | 0.00 | 0.63 | -10.16 | 181.74 | -32.87 | 100.47 | 0.5454 | -708.0 | -604.7 | |
| 0.71 | 6.82 | 0.42 | 4.05 | -11.40 | 181.52 | -33.10 | 102.66 | 0.5508 | 503.8 | -11.5 | |
| 0.00 | 2.30 | 0.00 | 1.37 | -12.26 | 181.10 | -33.51 | 104.10 | 0.5584 | -1018.0 | -862.0 | |
| 2.84 | 42.89 | 1.70 | 25.88 | -12.48 | 180.62 | -33.99 | 104.36 | 0.5656 | -1045.5 | -699.4 | |
| 0.27 | -21.00 | 0.16 | -21.00 | -12.60 | 180.57 | -34.04 | 104.55 | 0.5666 | -968.3 | 999999 | |
| 1.86 | 4.08 | 1.12 | 2.44 | -11.68 | 180.52 | -34.10 | 102.93 | 0.5654 | -867.7 | -669.7 | |
| 2.57 | 6.47 | 1.55 | 3.90 | -12.15 | 180.19 | -34.43 | 103.67 | 0.5710 | -863.4 | -661.5 | |
| 8.06 | -21.00 | 4.88 | -21.00 | -12.77 | 179.90 | -34.71 | 104.68 | 0.5763 | -942.1 | 999999 | |
| 1.95 | -21.00 | 1.18 | -21.00 | -13.10 | 179.74 | -34.88 | 105.20 | 0.5793 | -959.6 | 999999 | |
| 1.77 | -21.00 | 1.08 | -21.00 | -13.22 | 179.60 | -35.01 | 105.36 | 0.5814 | -711.5 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.43 | -9.69 | 180.11 | -34.50 | 99.34 | 0.5681 | 520.0 | 448.2 | |
| 0.00 | 1.33 | 0.00 | 0.82 | -15.46 | 179.12 | -35.49 | 108.96 | 0.5939 | 600.0 | 517.2 | |
| 0.00 | 0.97 | 0.00 | 0.59 | -12.03 | 179.57 | -35.05 | 103.31 | 0.5793 | -512.0 | -430.0 | |
| 0.00 | 1.33 | 0.00 | 0.83 | -16.96 | 178.41 | -36.20 | 111.15 | 0.6080 | 721.0 | 545.8 | |
| 0.00 | 0.53 | 0.00 | 0.33 | -15.46 | 178.54 | -36.07 | 108.76 | 0.6016 | 576.0 | 537.3 | |
| 0.00 | 1.15 | 0.00 | 0.72 | -16.71 | 177.88 | -36.73 | 110.56 | 0.6141 | 712.0 | 559.2 | |
| 0.00 | 0.89 | 0.00 | 0.56 | -17.14 | 177.78 | -36.83 | 111.20 | 0.6167 | 649.0 | 563.5 | |
| 0.00 | 1.06 | 0.00 | 0.66 | -10.43 | 178.13 | -36.48 | 100.33 | 0.5966 | 579.0 | 481.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
