SDO HMI 2014-04-18 10:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 8.33 | 0.00 | 6.18 | -22.96 | 170.14 | -43.92 | 119.16 | 0.7342 | -188.4 | -107.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-18 10:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.15 | 0.00 | 0.76 | -37.07 | 185.81 | -28.25 | 144.77 | 0.6570 | 436.0 | 409.6 | |
| 0.00 | 2.22 | 0.00 | 1.37 | -30.50 | 185.72 | -28.34 | 136.75 | 0.5992 | 778.0 | 471.6 | |
| 0.00 | 1.24 | 0.00 | 0.91 | -18.44 | 166.94 | -47.12 | 110.13 | 0.7427 | -512.0 | -410.5 | |
| 0.00 | 0.71 | 0.00 | 0.58 | -18.79 | 162.08 | -51.99 | 109.66 | 0.7943 | -582.0 | -500.1 | |
| 0.00 | 1.06 | 0.00 | 0.88 | -18.73 | 161.32 | -52.75 | 109.47 | 0.8017 | -357.0 | -332.2 | |
| 0.00 | 0.80 | 0.00 | 0.71 | -22.57 | 158.75 | -55.32 | 113.70 | 0.8314 | -422.0 | -345.8 | |
| 0.00 | 0.44 | 0.00 | 0.36 | -15.46 | 161.66 | -52.41 | 105.42 | 0.7945 | -299.0 | -291.2 | |
| 0.00 | 0.71 | 0.00 | 0.61 | -10.17 | 159.06 | -55.01 | 98.69 | 0.8179 | -549.0 | -512.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
