SDO HMI 2014-04-18 12:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 73.97 | 413.53 | 59.57 | 331.87 | 18.57 | 166.40 | -46.57 | 61.17 | 0.7866 | -323.2 | -190.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-18 12:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.06 | 0.00 | 0.77 | 20.42 | 172.86 | -40.11 | 55.56 | 0.7344 | 77.0 | 103.9 | |
| 13.55 | 320.97 | 10.37 | 248.30 | 18.11 | 168.62 | -44.35 | 60.71 | 0.7640 | -997.8 | -291.3 | |
| 17.98 | -2.00 | 13.89 | -2.00 | 18.84 | 168.38 | -44.59 | 59.96 | 0.7698 | -865.9 | 999999 | |
| 20.20 | -2.00 | 15.68 | -2.00 | 18.42 | 167.94 | -45.03 | 60.69 | 0.7721 | -784.3 | 999999 | |
| 1.86 | -2.00 | 1.46 | -2.00 | 18.84 | 167.48 | -45.49 | 60.41 | 0.7784 | -160.7 | 999999 | |
| 2.57 | -2.00 | 2.02 | -2.00 | 18.43 | 167.25 | -45.72 | 61.01 | 0.7787 | -452.5 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.84 | 17.98 | 166.72 | -46.25 | 61.79 | 0.7819 | -379.0 | -352.2 | |
| 0.00 | 1.33 | 0.00 | 1.08 | 17.75 | 165.35 | -47.61 | 62.69 | 0.7940 | -565.0 | -466.9 | |
| 0.00 | 1.15 | 0.00 | 0.94 | 17.80 | 165.15 | -47.82 | 62.72 | 0.7961 | -346.0 | -332.8 | |
| 0.89 | 2.57 | 0.74 | 2.14 | 16.91 | 163.65 | -49.32 | 64.41 | 0.8068 | 483.0 | 381.3 | |
| 0.00 | 2.39 | 0.00 | 2.03 | 17.72 | 163.15 | -49.82 | 63.67 | 0.8142 | 569.0 | 528.4 | |
| 0.00 | 0.97 | 0.00 | 0.86 | 19.01 | 162.03 | -50.94 | 62.65 | 0.8286 | 495.0 | 459.9 | |
| 0.00 | 3.46 | 0.00 | 3.12 | 20.24 | 161.43 | -51.54 | 61.51 | 0.8380 | 541.0 | 426.7 | |
| 0.00 | 1.06 | 0.00 | 0.92 | 18.08 | 162.26 | -50.70 | 63.61 | 0.8234 | 601.0 | 547.8 | |
| 0.00 | 0.97 | 0.00 | 0.84 | 17.28 | 162.52 | -50.44 | 64.42 | 0.8183 | 493.0 | 410.1 | |
| 0.00 | 0.97 | 0.00 | 0.84 | 17.60 | 162.15 | -50.82 | 64.21 | 0.8228 | 560.0 | 458.7 | |
| 0.00 | 0.97 | 0.00 | 0.85 | 17.98 | 161.85 | -51.12 | 63.89 | 0.8267 | 452.0 | 377.3 | |
| 0.00 | 0.80 | 0.00 | 0.70 | 17.15 | 161.67 | -51.30 | 64.91 | 0.8256 | 321.0 | 245.6 | |
| 7.62 | 73.80 | 6.90 | 67.64 | 18.95 | 160.72 | -52.25 | 63.24 | 0.8397 | 803.6 | 74.7 | |
| 3.81 | -19.00 | 3.49 | -19.00 | 19.14 | 160.32 | -52.65 | 63.18 | 0.8437 | 224.2 | 999999 | |
| 2.48 | -19.00 | 2.26 | -19.00 | 18.80 | 160.47 | -52.50 | 63.50 | 0.8413 | 770.8 | 999999 | |
| 3.01 | -19.00 | 2.76 | -19.00 | 18.73 | 160.19 | -52.78 | 63.69 | 0.8435 | 522.4 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
