SDO HMI 2014-04-18 18:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.68 | 9.92 | 2.13 | 13.38 | -19.74 | 140.70 | -68.97 | 109.15 | 0.9311 | 126.8 | 99.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-18 18:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.53 | 0.00 | 0.67 | -19.65 | 142.31 | -67.35 | 109.12 | 0.9215 | 355.0 | 343.5 | |
| 1.68 | 4.61 | 2.13 | 5.83 | -19.33 | 142.25 | -67.41 | 108.76 | 0.9218 | 483.7 | 382.2 | |
| 0.00 | 0.44 | 0.00 | 0.58 | -20.07 | 141.52 | -68.15 | 109.52 | 0.9266 | 205.0 | 176.4 | |
| 0.00 | 0.53 | 0.00 | 0.72 | -19.47 | 140.47 | -69.19 | 108.84 | 0.9328 | -436.0 | -388.0 | |
| 0.00 | 1.42 | 0.00 | 2.15 | -20.92 | 138.07 | -71.59 | 110.32 | 0.9465 | -177.0 | -125.4 | |
| 0.00 | 2.39 | 0.00 | 3.43 | -19.72 | 139.29 | -70.37 | 109.07 | 0.9397 | -73.0 | -22.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
