SDO HMI 2014-04-19 08:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.13 | 155.06 | 19.47 | 110.33 | -9.17 | 247.86 | 45.91 | 262.26 | 0.7172 | 564.0 | 175.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-19 08:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.10 | 108.44 | 15.40 | 79.30 | -8.88 | 249.46 | 47.51 | 262.76 | 0.7367 | 959.9 | 233.8 | |
| 0.80 | -1.00 | 0.57 | -1.00 | -8.84 | 248.73 | 46.78 | 262.80 | 0.7281 | 839.8 | 999999 | |
| 0.62 | 1.68 | 0.44 | 1.20 | -8.93 | 248.21 | 46.26 | 262.66 | 0.7220 | 734.6 | 664.8 | |
| 0.00 | 3.01 | 0.00 | 2.02 | -10.39 | 244.38 | 42.43 | 260.34 | 0.6754 | -770.0 | -667.5 | |
| 0.00 | 1.06 | 0.00 | 0.71 | -8.99 | 243.83 | 41.88 | 262.38 | 0.6676 | 420.0 | 452.0 | |
| 3.99 | 31.83 | 2.65 | 21.21 | -10.05 | 243.91 | 41.96 | 260.80 | 0.6692 | -840.8 | -25.2 | |
| 0.62 | 2.13 | 0.41 | 1.41 | -9.83 | 243.51 | 41.55 | 261.10 | 0.6639 | -692.1 | -519.0 | |
| 0.00 | 1.15 | 0.00 | 0.75 | -9.12 | 242.67 | 40.72 | 262.11 | 0.6525 | 473.0 | 413.2 | |
| 0.00 | 3.10 | 0.00 | 2.02 | -9.19 | 242.52 | 40.57 | 262.00 | 0.6506 | 797.0 | 637.4 | |
| 0.00 | 1.06 | 0.00 | 0.69 | -9.51 | 242.28 | 40.33 | 261.49 | 0.6477 | 666.0 | 539.1 | |
| 0.00 | 0.71 | 0.00 | 0.46 | -9.12 | 242.15 | 40.20 | 262.08 | 0.6457 | 710.0 | 659.6 | |
| 0.00 | 0.89 | 0.00 | 0.56 | -11.63 | 240.30 | 38.35 | 257.91 | 0.6237 | 647.0 | 573.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
