SDO HMI 2014-04-20 03:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.48 | 75.84 | 15.51 | 68.15 | -8.82 | 248.27 | 56.79 | 262.84 | 0.8345 | 397.2 | 200.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-20 03:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.85 | 61.64 | 9.12 | 57.03 | -8.77 | 249.48 | 58.00 | 262.90 | 0.8467 | 611.4 | 234.2 | |
| 3.02 | -1.00 | 2.77 | -1.00 | -8.89 | 249.17 | 57.68 | 262.77 | 0.8437 | 785.1 | 999999 | |
| 0.62 | -1.00 | 0.57 | -1.00 | -8.66 | 249.00 | 57.51 | 263.05 | 0.8422 | 668.4 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.78 | -7.40 | 247.60 | 56.12 | 264.59 | 0.8291 | 428.0 | 411.5 | |
| 0.53 | 2.84 | 0.43 | 2.30 | -10.14 | 244.13 | 52.65 | 261.21 | 0.7941 | -537.5 | -367.8 | |
| 0.00 | 1.24 | 0.00 | 0.98 | -8.31 | 242.86 | 51.37 | 263.51 | 0.7803 | 543.0 | 487.5 | |
| 0.00 | 0.80 | 0.00 | 0.63 | -9.15 | 242.63 | 51.14 | 262.44 | 0.7778 | 630.0 | 525.4 | |
| 0.00 | 0.98 | 0.00 | 0.76 | -9.49 | 242.60 | 51.11 | 262.00 | 0.7775 | 599.0 | 501.3 | |
| 0.00 | 0.89 | 0.00 | 0.69 | -8.30 | 242.18 | 50.69 | 263.53 | 0.7728 | 590.0 | 531.7 | |
| 0.80 | 2.04 | 0.61 | 1.56 | -9.35 | 241.41 | 49.93 | 262.15 | 0.7645 | -563.3 | -484.1 | |
| 2.66 | 4.52 | 2.01 | 3.42 | -8.61 | 240.80 | 49.32 | 263.12 | 0.7575 | -629.6 | -438.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
