SDO HMI 2014-04-20 12:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.57 | 72.12 | 25.54 | 52.10 | -19.82 | 140.99 | -45.56 | 112.52 | 0.7282 | 281.2 | 203.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-20 12:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.80 | 0.00 | 0.54 | -19.38 | 145.42 | -41.13 | 113.24 | 0.6776 | 720.0 | 591.8 | |
| 4.52 | 7.54 | 3.02 | 5.04 | -18.42 | 145.59 | -40.97 | 111.91 | 0.6728 | 725.0 | 535.3 | |
| 5.32 | 7.54 | 3.59 | 5.08 | -18.63 | 145.01 | -41.54 | 112.04 | 0.6803 | 726.5 | 481.7 | |
| 1.33 | 2.84 | 0.89 | 1.90 | -17.84 | 145.25 | -41.31 | 110.96 | 0.6752 | -632.3 | -463.1 | |
| 0.00 | 1.15 | 0.00 | 0.79 | -19.22 | 144.32 | -42.24 | 112.65 | 0.6901 | 195.0 | 221.2 | |
| 0.00 | 0.98 | 0.00 | 0.67 | -19.21 | 143.67 | -42.89 | 112.44 | 0.6976 | 456.0 | 399.0 | |
| 5.23 | 7.63 | 3.58 | 5.22 | -17.94 | 143.81 | -42.75 | 110.69 | 0.6926 | 732.1 | 455.2 | |
| 0.00 | 0.98 | 0.00 | 0.67 | -17.67 | 143.58 | -42.97 | 110.25 | 0.6946 | 528.0 | 423.0 | |
| 0.00 | 0.27 | 0.00 | 0.18 | -17.41 | 143.31 | -43.24 | 109.81 | 0.6971 | 411.0 | 334.0 | |
| 2.31 | 4.97 | 1.66 | 3.58 | -20.06 | 141.13 | -45.42 | 112.87 | 0.7285 | 777.6 | 557.9 | |
| 1.60 | 3.02 | 1.16 | 2.19 | -20.86 | 140.73 | -45.82 | 113.83 | 0.7349 | 587.4 | 448.6 | |
| 0.00 | 0.89 | 0.00 | 0.66 | -21.09 | 139.94 | -46.62 | 113.91 | 0.7441 | 495.0 | 427.3 | |
| 0.00 | 2.48 | 0.00 | 1.83 | -20.40 | 140.07 | -46.48 | 113.04 | 0.7409 | 667.0 | 509.3 | |
| 7.72 | 11.88 | 5.95 | 9.15 | -21.90 | 137.79 | -48.76 | 114.40 | 0.7684 | -700.9 | -482.8 | |
| 2.57 | 4.35 | 1.93 | 3.26 | -19.56 | 138.80 | -47.76 | 111.62 | 0.7527 | 636.2 | 447.4 | |
| 1.69 | 3.28 | 1.26 | 2.45 | -19.29 | 138.90 | -47.65 | 111.28 | 0.7509 | 681.7 | 538.7 | |
| 0.71 | 1.86 | 0.54 | 1.41 | -20.04 | 138.32 | -48.24 | 112.13 | 0.7588 | 457.6 | 409.8 | |
| 0.00 | 1.15 | 0.00 | 0.87 | -20.19 | 138.25 | -48.30 | 112.31 | 0.7598 | 435.0 | 378.9 | |
| 2.57 | 4.52 | 1.96 | 3.45 | -20.01 | 137.94 | -48.62 | 112.01 | 0.7627 | 425.5 | 281.4 | |
| 0.00 | 2.48 | 0.00 | 1.97 | -22.10 | 136.44 | -50.11 | 114.32 | 0.7824 | -583.0 | -422.0 | |
| 0.00 | 0.62 | 0.00 | 0.49 | -21.63 | 136.11 | -50.44 | 113.65 | 0.7847 | -372.0 | -331.0 | |
| 0.00 | 0.89 | 0.00 | 0.70 | -21.47 | 136.13 | -50.42 | 113.46 | 0.7841 | -503.0 | -469.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
