SDO HMI 2014-04-20 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.24 | 51.78 | 10.02 | 63.35 | -23.11 | 118.09 | -66.27 | 113.03 | 0.9160 | 462.4 | 380.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-20 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.41 | 41.76 | 6.49 | 49.97 | -23.13 | 118.69 | -65.67 | 113.09 | 0.9126 | 758.0 | 438.9 | |
| 0.00 | 0.53 | 0.00 | 0.66 | -23.65 | 117.85 | -66.51 | 113.58 | 0.9183 | 239.0 | 258.2 | |
| 2.48 | 4.61 | 3.08 | 5.71 | -23.10 | 117.82 | -66.53 | 112.98 | 0.9182 | 249.1 | 189.7 | |
| 0.35 | 2.48 | 0.45 | 3.14 | -22.82 | 117.18 | -67.18 | 112.63 | 0.9221 | 270.8 | 194.4 | |
| 0.00 | 0.80 | 0.00 | 1.00 | -22.61 | 117.39 | -66.97 | 112.41 | 0.9207 | 250.0 | 212.1 | |
| 0.00 | 1.60 | 0.00 | 2.87 | -23.22 | 109.52 | -74.83 | 112.70 | 0.9627 | -86.0 | -67.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
