SDO HMI 2014-04-20 19:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.62 | 32.45 | 9.41 | 39.49 | -8.69 | 249.11 | 66.41 | 262.77 | 0.9145 | 420.1 | 138.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-20 19:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.70 | 0.00 | 5.80 | -8.23 | 249.51 | 66.81 | 263.26 | 0.9178 | 85.0 | 82.4 | |
| 7.62 | 25.36 | 9.41 | 31.36 | -8.75 | 249.53 | 66.83 | 262.69 | 0.9178 | 539.3 | 171.0 | |
| 0.00 | 1.06 | 0.00 | 1.09 | -9.36 | 244.08 | 61.39 | 262.14 | 0.8764 | 367.0 | 348.3 | |
| 0.00 | 1.33 | 0.00 | 1.24 | -8.63 | 240.95 | 58.25 | 263.04 | 0.8491 | -313.0 | -354.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
