SDO HMI 2014-04-20 20:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.68 | 103.21 | 20.75 | 69.28 | -19.78 | 141.25 | -40.89 | 113.91 | 0.6751 | 182.3 | 245.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-20 20:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.39 | 0.00 | 1.50 | -18.92 | 145.86 | -36.28 | 114.44 | 0.6171 | 778.0 | 587.2 | |
| 1.68 | 5.59 | 1.06 | 3.51 | -18.42 | 145.83 | -36.31 | 113.65 | 0.6155 | 959.3 | 689.7 | |
| 0.00 | 0.53 | 0.00 | 0.34 | -19.46 | 145.45 | -36.70 | 115.10 | 0.6244 | 686.0 | 627.8 | |
| 0.00 | 0.80 | 0.00 | 0.50 | -17.85 | 145.66 | -36.49 | 112.68 | 0.6157 | -490.0 | -463.6 | |
| 3.10 | 5.94 | 1.96 | 3.76 | -18.57 | 145.16 | -36.98 | 113.60 | 0.6246 | 869.6 | 533.5 | |
| 0.00 | 0.71 | 0.00 | 0.45 | -19.48 | 144.68 | -37.46 | 114.80 | 0.6339 | 637.0 | 500.5 | |
| 0.00 | 1.15 | 0.00 | 0.74 | -19.32 | 144.07 | -38.07 | 114.31 | 0.6407 | 500.0 | 464.0 | |
| 0.00 | 0.89 | 0.00 | 0.56 | -17.51 | 144.51 | -37.63 | 111.70 | 0.6290 | 796.0 | 643.5 | |
| 4.97 | 17.73 | 3.17 | 11.36 | -17.77 | 144.24 | -37.90 | 112.01 | 0.6332 | 979.6 | 505.9 | |
| 0.80 | -9.00 | 0.51 | -9.00 | -18.14 | 144.07 | -38.07 | 112.51 | 0.6366 | 776.7 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.68 | -18.51 | 143.97 | -38.17 | 113.03 | 0.6391 | 432.0 | 408.5 | |
| 0.00 | 0.98 | 0.00 | 0.62 | -17.20 | 143.94 | -38.20 | 111.02 | 0.6351 | 818.0 | 650.6 | |
| 0.80 | 2.39 | 0.52 | 1.56 | -19.18 | 143.13 | -39.01 | 113.72 | 0.6517 | -812.4 | -689.0 | |
| 0.00 | 2.39 | 0.00 | 1.54 | -17.27 | 143.60 | -38.54 | 111.02 | 0.6397 | 549.0 | 465.0 | |
| 0.00 | 2.93 | 0.00 | 1.98 | -20.75 | 141.01 | -41.13 | 115.21 | 0.6822 | 667.0 | 485.9 | |
| 2.93 | 6.74 | 1.97 | 4.53 | -20.04 | 141.11 | -41.03 | 114.23 | 0.6786 | 821.1 | 381.7 | |
| 0.00 | 0.80 | 0.00 | 0.55 | -21.83 | 139.89 | -42.25 | 116.31 | 0.6986 | 643.0 | 510.1 | |
| 0.00 | 0.98 | 0.00 | 0.67 | -20.92 | 140.13 | -42.01 | 115.14 | 0.6929 | 552.0 | 456.1 | |
| 0.00 | 5.76 | 0.00 | 3.94 | -20.58 | 140.16 | -41.98 | 114.66 | 0.6914 | 741.0 | 582.0 | |
| 0.00 | 0.35 | 0.00 | 0.24 | -20.36 | 140.11 | -42.04 | 114.33 | 0.6913 | 413.0 | 351.2 | |
| 0.89 | 4.17 | 0.60 | 2.85 | -20.04 | 140.17 | -41.97 | 113.91 | 0.6896 | 677.6 | 467.6 | |
| 0.00 | 0.89 | 0.00 | 0.61 | -20.80 | 139.69 | -42.45 | 114.82 | 0.6975 | 246.0 | 199.5 | |
| 0.00 | 1.15 | 0.00 | 0.80 | -21.08 | 139.06 | -43.08 | 114.99 | 0.7054 | -163.0 | -176.0 | |
| 5.94 | 10.99 | 4.19 | 7.74 | -21.52 | 138.45 | -43.69 | 115.38 | 0.7136 | -871.9 | -608.8 | |
| 0.00 | 1.24 | 0.00 | 0.87 | -21.02 | 138.59 | -43.55 | 114.75 | 0.7105 | -538.0 | -415.3 | |
| 0.00 | 1.60 | 0.00 | 1.12 | -20.68 | 138.67 | -43.47 | 114.31 | 0.7085 | -778.0 | -643.6 | |
| 0.00 | 0.80 | 0.00 | 0.56 | -20.80 | 138.59 | -43.56 | 114.44 | 0.7099 | -598.0 | -502.0 | |
| 0.00 | 2.22 | 0.00 | 1.53 | -19.32 | 139.06 | -43.08 | 112.54 | 0.7002 | 813.0 | 710.0 | |
| 1.33 | 3.19 | 0.92 | 2.21 | -19.53 | 138.90 | -43.24 | 112.79 | 0.7026 | 732.0 | 508.6 | |
| 6.65 | 9.84 | 4.73 | 7.00 | -21.87 | 137.95 | -44.19 | 115.69 | 0.7201 | -811.9 | -548.8 | |
| 0.44 | 1.60 | 0.31 | 1.11 | -19.89 | 138.60 | -43.54 | 113.19 | 0.7071 | 681.0 | 584.3 | |
| 0.00 | 1.15 | 0.00 | 0.81 | -20.50 | 138.29 | -43.85 | 113.94 | 0.7123 | -457.0 | -471.4 | |
| 1.15 | 2.84 | 0.81 | 2.00 | -19.92 | 138.05 | -44.09 | 113.07 | 0.7133 | 547.4 | 382.9 | |
| 0.00 | 1.42 | 0.00 | 1.04 | -21.81 | 135.90 | -46.24 | 114.97 | 0.7420 | -609.0 | -517.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
