SDO HMI 2014-04-22 11:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 73.81 | 414.00 | 39.87 | 223.84 | 17.76 | 166.68 | 5.99 | 345.60 | 0.4014 | -706.8 | -294.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-22 11:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.15 | 380.95 | 4.96 | 206.04 | 17.94 | 167.57 | 6.89 | 343.65 | 0.4072 | -1069.1 | -379.9 | |
| 58.79 | -1.00 | 31.77 | -1.00 | 17.71 | 167.06 | 6.37 | 344.66 | 0.4013 | -1392.6 | 999999 | |
| 0.00 | 2.31 | 0.00 | 1.24 | 17.40 | 163.91 | 3.22 | 351.98 | 0.3861 | 634.0 | 609.0 | |
| 0.00 | 1.42 | 0.00 | 0.76 | 17.92 | 163.31 | 2.63 | 353.60 | 0.3932 | 908.0 | 777.7 | |
| 0.00 | 2.40 | 0.00 | 1.29 | 17.59 | 163.31 | 2.62 | 353.52 | 0.3880 | 883.0 | 781.3 | |
| 0.00 | 0.80 | 0.00 | 0.43 | 18.18 | 163.13 | 2.44 | 354.12 | 0.3971 | 693.0 | 523.2 | |
| 0.00 | 1.51 | 0.00 | 0.83 | 19.93 | 162.87 | 2.18 | 355.14 | 0.4245 | 780.0 | 550.1 | |
| 0.00 | 1.07 | 0.00 | 0.58 | 18.34 | 162.30 | 1.62 | 356.13 | 0.3986 | 831.0 | 682.9 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 18.18 | 162.27 | 1.59 | 356.18 | 0.3959 | 831.0 | 742.7 | |
| 0.00 | 1.42 | 0.00 | 0.76 | 17.85 | 162.11 | 1.42 | 356.51 | 0.3905 | 870.0 | 699.8 | |
| 0.00 | 5.77 | 0.00 | 3.09 | 17.29 | 161.31 | 0.63 | 358.42 | 0.3809 | 1024.0 | 857.5 | |
| 0.00 | 2.22 | 0.00 | 1.19 | 17.52 | 161.13 | 0.44 | 358.90 | 0.3846 | 864.0 | 585.2 | |
| 0.00 | 1.69 | 0.00 | 0.91 | 17.95 | 160.62 | -0.06 | 0.16 | 0.3914 | 696.0 | 483.4 | |
| 1.07 | 2.66 | 0.57 | 1.43 | 17.88 | 160.37 | -0.32 | 0.78 | 0.3904 | 819.6 | 574.8 | |
| 4.80 | 7.73 | 2.57 | 4.14 | 17.39 | 160.24 | -0.44 | 1.11 | 0.3825 | 1112.7 | 789.0 | |
| 0.00 | 1.07 | 0.00 | 0.62 | 26.47 | 159.35 | -1.34 | 2.29 | 0.5244 | 544.0 | 356.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
