SDO HMI 2014-04-24 09:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.92 | 113.62 | 22.26 | 92.29 | -10.33 | 187.92 | 52.56 | 260.64 | 0.7935 | 156.0 | 212.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-24 09:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.27 | 0.00 | 0.23 | -10.72 | 189.79 | 54.43 | 260.25 | 0.8132 | 280.0 | 284.7 | |
| 5.69 | 58.06 | 4.76 | 48.61 | -10.09 | 189.26 | 53.90 | 261.01 | 0.8076 | 644.1 | 273.0 | |
| 3.20 | -2.00 | 2.68 | -2.00 | -10.36 | 189.33 | 53.97 | 260.68 | 0.8084 | 617.2 | 999999 | |
| 2.49 | -2.00 | 2.07 | -2.00 | -10.17 | 188.97 | 53.61 | 260.91 | 0.8047 | 836.9 | 999999 | |
| 4.53 | 23.29 | 3.74 | 19.15 | -9.76 | 188.67 | 53.31 | 261.40 | 0.8015 | 983.0 | 483.4 | |
| 0.00 | 1.33 | 0.00 | 1.08 | -10.92 | 187.77 | 52.41 | 259.91 | 0.7925 | 631.0 | 556.1 | |
| 0.00 | 1.24 | 0.00 | 1.02 | -13.01 | 188.09 | 52.73 | 257.30 | 0.7971 | 523.0 | 471.4 | |
| 0.00 | 1.24 | 0.00 | 1.01 | -13.35 | 187.99 | 52.63 | 256.86 | 0.7963 | 504.0 | 416.8 | |
| 0.00 | 0.80 | 0.00 | 0.63 | -10.85 | 186.46 | 51.10 | 259.93 | 0.7785 | -418.0 | -400.6 | |
| 0.00 | 1.16 | 0.00 | 0.89 | -11.19 | 185.37 | 50.01 | 259.41 | 0.7669 | -237.0 | -286.5 | |
| 0.00 | 1.42 | 0.00 | 1.08 | -9.42 | 184.90 | 49.54 | 261.71 | 0.7608 | -253.0 | -338.4 | |
| 0.00 | 1.07 | 0.00 | 0.81 | -9.61 | 184.79 | 49.43 | 261.46 | 0.7597 | -497.0 | -397.6 | |
| 1.16 | 3.91 | 0.88 | 2.97 | -10.74 | 184.79 | 49.43 | 259.97 | 0.7602 | -455.4 | -472.1 | |
| 1.07 | 13.25 | 0.81 | 9.98 | -11.09 | 184.54 | 49.18 | 259.49 | 0.7576 | -393.8 | -500.2 | |
| 7.65 | -14.00 | 5.75 | -14.00 | -10.80 | 184.33 | 48.97 | 259.86 | 0.7551 | -838.1 | 999999 | |
| 0.00 | 0.62 | 0.00 | 0.46 | -10.45 | 183.10 | 47.74 | 260.24 | 0.7408 | -331.0 | -466.7 | |
| 0.00 | 2.76 | 0.00 | 2.02 | -11.03 | 182.95 | 47.59 | 259.44 | 0.7394 | -484.0 | -486.9 | |
| 2.13 | 3.20 | 1.57 | 2.35 | -12.25 | 183.04 | 47.68 | 257.80 | 0.7415 | 462.3 | 377.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
