SDO HMI 2014-04-28 19:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.32 | 201.68 | 21.30 | 131.78 | -23.60 | 114.19 | 37.18 | 238.11 | 0.6542 | 256.9 | 266.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-04-28 19:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.36 | 0.00 | 0.24 | -24.26 | 115.56 | 38.55 | 238.02 | 0.6721 | 326.0 | 270.5 | |
| 31.43 | 171.95 | 20.71 | 113.21 | -23.38 | 115.00 | 37.99 | 238.96 | 0.6617 | 1078.6 | 404.2 | |
| 0.00 | 0.98 | 0.00 | 0.65 | -24.08 | 115.20 | 38.19 | 238.08 | 0.6673 | -29.0 | 27.5 | |
| 0.89 | 2.49 | 0.59 | 1.65 | -24.46 | 114.70 | 37.69 | 237.30 | 0.6637 | 692.9 | 555.4 | |
| 0.00 | 0.53 | 0.00 | 0.37 | -28.49 | 115.77 | 38.76 | 232.46 | 0.6962 | 421.0 | 413.5 | |
| 0.00 | 1.69 | 0.00 | 1.07 | -20.99 | 112.76 | 35.75 | 241.29 | 0.6242 | -592.0 | -472.8 | |
| 0.00 | 0.89 | 0.00 | 0.56 | -21.81 | 112.27 | 35.26 | 239.80 | 0.6224 | -623.0 | -533.4 | |
| 0.00 | 0.71 | 0.00 | 0.44 | -21.33 | 111.46 | 34.46 | 240.06 | 0.6104 | -518.0 | -438.9 | |
| 0.00 | 1.96 | 0.00 | 1.22 | -21.18 | 111.26 | 34.26 | 240.18 | 0.6072 | -745.0 | -658.3 | |
| 0.00 | 0.71 | 0.00 | 0.45 | -23.04 | 110.91 | 33.90 | 237.15 | 0.6132 | -636.0 | -543.0 | |
| 0.00 | 1.96 | 0.00 | 1.22 | -22.35 | 110.68 | 33.67 | 238.05 | 0.6065 | -707.0 | -625.7 | |
| 0.00 | 1.07 | 0.00 | 0.66 | -22.66 | 110.02 | 33.01 | 237.16 | 0.6006 | -542.0 | -473.2 | |
| 0.00 | 1.07 | 0.00 | 0.66 | -23.60 | 109.73 | 32.72 | 235.55 | 0.6029 | -619.0 | -449.2 | |
| 0.00 | 1.34 | 0.00 | 0.84 | -26.02 | 110.05 | 33.05 | 232.26 | 0.6220 | -629.0 | -489.0 | |
| 0.00 | 1.07 | 0.00 | 0.67 | -25.97 | 108.84 | 31.83 | 231.46 | 0.6085 | -655.0 | -512.1 | |
| 0.00 | 1.60 | 0.00 | 1.00 | -26.11 | 108.57 | 31.56 | 231.06 | 0.6065 | -680.0 | -550.7 | |
| 0.00 | 0.89 | 0.00 | 0.56 | -27.88 | 107.76 | 30.76 | 227.95 | 0.6110 | -514.0 | -425.8 | |
| 0.00 | 1.69 | 0.00 | 1.05 | -27.69 | 107.70 | 30.70 | 228.17 | 0.6089 | -602.0 | -607.7 | |
| 0.00 | 0.80 | 0.00 | 0.47 | -22.32 | 105.55 | 28.54 | 234.44 | 0.5455 | -625.0 | -510.8 | |
| 0.00 | 1.60 | 0.00 | 0.99 | -27.69 | 106.52 | 29.52 | 227.19 | 0.5968 | -623.0 | -503.1 | |
| 0.00 | 1.25 | 0.00 | 0.77 | -27.67 | 106.24 | 29.23 | 226.99 | 0.5937 | -742.0 | -670.7 | |
| 0.00 | 1.87 | 0.00 | 1.12 | -26.40 | 104.01 | 27.00 | 226.81 | 0.5600 | -833.0 | -702.6 | |
| 0.00 | 1.78 | 0.00 | 1.07 | -27.58 | 103.94 | 26.93 | 225.05 | 0.5694 | -760.0 | -614.7 | |
| 0.00 | 1.42 | 0.00 | 0.84 | -29.34 | 99.34 | 22.34 | 217.84 | 0.5421 | -697.0 | -613.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
