SDO HMI 2014-05-09 00:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.77 | 197.22 | 28.15 | 170.10 | 14.82 | 249.76 | -52.30 | 69.23 | 0.8201 | -715.4 | -184.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-09 00:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.77 | 193.02 | 28.15 | 166.12 | 14.85 | 249.86 | -52.20 | 69.16 | 0.8193 | -878.9 | -200.4 | |
| 0.00 | 1.07 | 0.00 | 0.98 | 13.07 | 247.02 | -55.03 | 72.06 | 0.8412 | 408.0 | 343.2 | |
| 0.00 | 1.16 | 0.00 | 1.07 | 13.38 | 246.53 | -55.52 | 71.83 | 0.8462 | 385.0 | 365.0 | |
| 0.00 | 1.34 | 0.00 | 1.24 | 13.16 | 246.39 | -55.67 | 72.11 | 0.8471 | 478.0 | 365.3 | |
| 0.00 | 0.63 | 0.00 | 0.69 | 14.28 | 240.71 | -61.35 | 72.17 | 0.8952 | 470.0 | 407.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
