SDO HMI 2014-05-09 16:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.30 | 203.75 | 33.42 | 225.67 | -13.63 | 230.03 | -63.24 | 103.59 | 0.8896 | 298.8 | 143.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-09 16:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.54 | 0.00 | 0.42 | -12.08 | 242.90 | -50.36 | 102.95 | 0.7750 | 474.0 | 405.8 | |
| 0.00 | 0.98 | 0.00 | 0.82 | -15.55 | 240.08 | -53.18 | 106.91 | 0.8083 | 376.0 | 313.0 | |
| 0.00 | 0.98 | 0.00 | 0.82 | -10.06 | 239.79 | -53.48 | 100.10 | 0.8059 | 512.0 | 487.2 | |
| 0.00 | 1.16 | 0.00 | 0.97 | -10.11 | 239.52 | -53.75 | 100.14 | 0.8087 | 507.0 | 440.4 | |
| 0.00 | 1.34 | 0.00 | 1.14 | -11.26 | 239.01 | -54.26 | 101.50 | 0.8146 | 505.0 | 409.4 | |
| 0.00 | 0.90 | 0.00 | 0.77 | -10.14 | 238.24 | -55.03 | 100.09 | 0.8215 | 388.0 | 347.8 | |
| 0.00 | 0.98 | 0.00 | 0.93 | -17.39 | 235.28 | -57.98 | 108.42 | 0.8549 | 430.0 | 330.9 | |
| 15.22 | 121.84 | 14.25 | 114.48 | -11.63 | 235.21 | -58.06 | 101.66 | 0.8508 | 881.1 | 285.9 | |
| 0.00 | 1.79 | 0.00 | 1.73 | -7.92 | 233.95 | -59.32 | 97.26 | 0.8607 | 418.0 | 320.8 | |
| 0.00 | 1.07 | 0.00 | 1.14 | -13.74 | 231.03 | -62.24 | 103.81 | 0.8870 | 520.0 | 409.6 | |
| 0.00 | 2.51 | 0.00 | 2.57 | -11.04 | 232.08 | -61.18 | 100.81 | 0.8774 | 390.0 | 306.9 | |
| 0.00 | 0.81 | 0.00 | 0.88 | -13.60 | 230.07 | -63.20 | 103.59 | 0.8944 | 174.0 | 215.4 | |
| 0.00 | 0.81 | 0.00 | 1.10 | -19.46 | 224.63 | -68.64 | 109.62 | 0.9337 | -77.0 | -99.1 | |
| 0.00 | 1.25 | 0.00 | 1.61 | -14.39 | 225.95 | -67.32 | 104.23 | 0.9237 | 312.0 | 187.4 | |
| 0.00 | 2.33 | 0.00 | 3.10 | -15.81 | 224.99 | -68.27 | 105.72 | 0.9301 | -146.0 | -200.1 | |
| 0.00 | 1.07 | 0.00 | 1.42 | -15.03 | 225.19 | -68.08 | 104.89 | 0.9287 | -501.0 | -461.2 | |
| 0.63 | 4.03 | 0.84 | 5.43 | -15.27 | 224.86 | -68.41 | 105.13 | 0.9308 | -590.4 | -391.6 | |
| 0.00 | 0.27 | 0.00 | 0.35 | -13.88 | 225.77 | -67.50 | 103.67 | 0.9247 | -140.0 | -226.3 | |
| 0.63 | -17.00 | 0.85 | -17.00 | -15.41 | 224.58 | -68.68 | 105.27 | 0.9325 | -260.3 | 999999 | |
| 0.00 | 2.24 | 0.00 | 2.75 | -11.12 | 226.91 | -66.36 | 100.71 | 0.9165 | -452.0 | -384.1 | |
| 0.00 | 1.52 | 0.00 | 2.05 | -14.86 | 224.80 | -68.47 | 104.69 | 0.9311 | -413.0 | -432.2 | |
| 7.52 | 42.79 | 11.06 | 63.17 | -17.08 | 222.89 | -70.38 | 106.98 | 0.9428 | 350.7 | 30.9 | |
| 0.00 | 1.79 | 0.00 | 2.39 | -14.21 | 224.97 | -68.30 | 104.00 | 0.9298 | 178.0 | 128.4 | |
| 0.00 | 2.33 | 0.00 | 3.30 | -15.07 | 223.58 | -69.69 | 104.87 | 0.9384 | -458.0 | -408.5 | |
| 0.00 | 1.88 | 0.00 | 2.57 | -13.74 | 224.32 | -68.95 | 103.47 | 0.9337 | -301.0 | -254.8 | |
| 4.30 | 6.54 | 6.42 | 9.76 | -14.36 | 222.42 | -70.85 | 104.07 | 0.9449 | -335.3 | -194.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
