SDO HMI 2014-05-10 14:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 57.52 | 307.31 | 46.17 | 245.33 | -13.17 | 230.10 | -51.05 | 104.25 | 0.7795 | 226.3 | 148.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-10 14:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.07 | 0.00 | 0.70 | -11.34 | 241.10 | -40.05 | 103.78 | 0.6519 | 690.0 | 562.6 | |
| 0.00 | 1.16 | 0.00 | 0.80 | -17.34 | 238.86 | -42.29 | 111.91 | 0.6946 | 539.0 | 431.0 | |
| 0.00 | 1.07 | 0.00 | 0.71 | -10.59 | 239.92 | -41.23 | 102.41 | 0.6657 | 790.0 | 658.3 | |
| 0.00 | 2.06 | 0.00 | 1.36 | -10.13 | 239.91 | -41.24 | 101.72 | 0.6650 | 811.0 | 721.5 | |
| 0.00 | 0.99 | 0.00 | 0.65 | -9.58 | 239.83 | -41.32 | 100.88 | 0.6652 | 752.0 | 611.1 | |
| 0.00 | 1.97 | 0.00 | 1.33 | -13.04 | 238.91 | -42.24 | 105.80 | 0.6829 | 596.0 | 502.6 | |
| 0.00 | 2.33 | 0.00 | 1.55 | -9.84 | 239.34 | -41.81 | 101.18 | 0.6719 | 449.0 | 415.8 | |
| 0.00 | 0.27 | 0.00 | 0.18 | -6.92 | 237.19 | -43.96 | 96.67 | 0.6961 | 504.0 | 470.3 | |
| 7.08 | 127.65 | 5.01 | 91.17 | -11.48 | 235.84 | -45.31 | 102.97 | 0.7172 | 998.3 | 381.2 | |
| 16.12 | -9.00 | 11.57 | -9.00 | -11.48 | 235.13 | -46.02 | 102.86 | 0.7256 | 863.1 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.78 | -11.33 | 234.53 | -46.62 | 102.57 | 0.7324 | 323.0 | 182.6 | |
| 0.00 | 0.90 | 0.00 | 0.64 | -8.44 | 234.80 | -46.35 | 98.63 | 0.7262 | 563.0 | 442.5 | |
| 3.14 | 5.46 | 2.25 | 3.92 | -7.89 | 234.80 | -46.35 | 97.87 | 0.7259 | 668.3 | 501.6 | |
| 0.00 | 1.52 | 0.00 | 1.10 | -7.39 | 234.47 | -46.68 | 97.16 | 0.7295 | 285.0 | 317.6 | |
| 8.06 | 16.75 | 5.94 | 12.35 | -10.71 | 233.57 | -47.58 | 101.60 | 0.7427 | 594.9 | 353.1 | |
| 1.61 | -15.00 | 1.19 | -15.00 | -10.95 | 233.43 | -47.72 | 101.90 | 0.7446 | 384.8 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.59 | -10.01 | 233.53 | -47.62 | 100.64 | 0.7424 | 549.0 | 444.1 | |
| 0.54 | 1.70 | 0.40 | 1.26 | -10.21 | 233.35 | -47.80 | 100.90 | 0.7447 | 431.8 | 317.8 | |
| 0.00 | 0.99 | 0.00 | 0.73 | -10.61 | 233.23 | -47.92 | 101.41 | 0.7466 | -324.0 | -316.5 | |
| 0.00 | 1.16 | 0.00 | 0.86 | -10.14 | 233.14 | -48.01 | 100.78 | 0.7471 | 195.0 | 157.6 | |
| 0.00 | 1.52 | 0.00 | 1.15 | -12.61 | 232.48 | -48.67 | 103.96 | 0.7574 | -543.0 | -392.2 | |
| 0.00 | 1.07 | 0.00 | 0.79 | -6.11 | 233.69 | -47.46 | 95.38 | 0.7381 | 572.0 | 472.5 | |
| 0.00 | 2.42 | 0.00 | 1.80 | -10.29 | 232.92 | -48.23 | 100.95 | 0.7497 | -763.0 | -632.1 | |
| 0.00 | 0.63 | 0.00 | 0.47 | -9.43 | 233.04 | -48.11 | 99.82 | 0.7475 | 560.0 | 470.1 | |
| 0.00 | 0.54 | 0.00 | 0.41 | -13.45 | 232.11 | -49.04 | 105.01 | 0.7627 | 412.0 | 402.5 | |
| 0.00 | 0.90 | 0.00 | 0.67 | -10.37 | 232.81 | -48.34 | 101.05 | 0.7510 | -368.0 | -378.9 | |
| 0.00 | 2.24 | 0.00 | 1.68 | -9.63 | 232.63 | -48.51 | 100.05 | 0.7523 | 346.0 | 304.8 | |
| 0.00 | 0.99 | 0.00 | 0.73 | -6.24 | 233.08 | -48.07 | 95.53 | 0.7453 | 415.0 | 323.7 | |
| 0.00 | 1.07 | 0.00 | 0.81 | -10.66 | 232.28 | -48.87 | 101.37 | 0.7573 | -683.0 | -534.9 | |
| 0.00 | 3.85 | 0.00 | 2.92 | -10.90 | 232.18 | -48.97 | 101.68 | 0.7587 | -379.0 | -459.5 | |
| 0.00 | 3.49 | 0.00 | 2.71 | -13.20 | 231.26 | -49.88 | 104.55 | 0.7715 | 592.0 | 448.2 | |
| 0.00 | 1.61 | 0.00 | 1.25 | -12.83 | 231.27 | -49.88 | 104.07 | 0.7709 | 222.0 | 298.6 | |
| 0.00 | 0.81 | 0.00 | 0.63 | -12.95 | 231.04 | -50.10 | 104.19 | 0.7735 | 466.0 | 391.7 | |
| 0.00 | 1.43 | 0.00 | 1.08 | -7.26 | 232.11 | -49.04 | 96.86 | 0.7568 | -665.0 | -548.2 | |
| 0.00 | 0.72 | 0.00 | 0.57 | -13.91 | 230.42 | -50.73 | 105.33 | 0.7814 | 382.0 | 324.8 | |
| 0.00 | 1.34 | 0.00 | 1.02 | -7.01 | 231.91 | -49.24 | 96.52 | 0.7589 | -493.0 | -446.0 | |
| 0.45 | 1.52 | 0.34 | 1.17 | -7.31 | 231.25 | -49.90 | 96.89 | 0.7665 | -467.8 | -399.4 | |
| 1.43 | 2.96 | 1.11 | 2.29 | -8.00 | 230.90 | -50.25 | 97.77 | 0.7707 | -518.9 | -424.1 | |
| 0.00 | 1.34 | 0.00 | 1.06 | -10.16 | 230.03 | -51.12 | 100.50 | 0.7815 | -125.0 | -236.1 | |
| 0.00 | 0.72 | 0.00 | 0.57 | -11.19 | 229.54 | -51.61 | 101.75 | 0.7876 | -746.0 | -632.5 | |
| 0.00 | 1.07 | 0.00 | 0.86 | -11.30 | 229.41 | -51.74 | 101.89 | 0.7891 | -753.0 | -684.9 | |
| 0.00 | 1.07 | 0.00 | 0.86 | -10.93 | 229.30 | -51.84 | 101.40 | 0.7898 | -550.0 | -440.6 | |
| 0.00 | 0.90 | 0.00 | 0.74 | -11.94 | 228.48 | -52.67 | 102.59 | 0.7993 | -620.0 | -573.8 | |
| 0.00 | 0.99 | 0.00 | 0.82 | -12.29 | 228.12 | -53.03 | 102.99 | 0.8033 | -491.0 | -414.7 | |
| 0.00 | 2.42 | 0.00 | 2.05 | -14.55 | 227.28 | -53.87 | 105.66 | 0.8141 | 569.0 | 395.4 | |
| 0.00 | 0.81 | 0.00 | 0.69 | -14.45 | 227.10 | -54.05 | 105.51 | 0.8157 | 473.0 | 397.7 | |
| 0.00 | 1.34 | 0.00 | 1.20 | -17.14 | 225.63 | -55.52 | 108.54 | 0.8330 | 481.0 | 412.9 | |
| 0.00 | 2.24 | 0.00 | 1.92 | -14.37 | 226.70 | -54.45 | 105.36 | 0.8195 | 526.0 | 316.9 | |
| 0.00 | 1.61 | 0.00 | 1.42 | -15.80 | 225.87 | -55.28 | 106.98 | 0.8291 | -442.0 | -362.2 | |
| 0.00 | 1.61 | 0.00 | 1.40 | -14.42 | 226.36 | -54.79 | 105.38 | 0.8229 | 394.0 | 292.6 | |
| 0.00 | 2.78 | 0.00 | 2.43 | -15.15 | 226.02 | -55.13 | 106.22 | 0.8269 | -507.0 | -379.5 | |
| 0.00 | 0.54 | 0.00 | 0.46 | -12.00 | 227.00 | -54.15 | 102.50 | 0.8143 | -390.0 | -351.0 | |
| 0.00 | 0.27 | 0.00 | 0.24 | -15.78 | 225.54 | -55.61 | 106.91 | 0.8321 | -403.0 | -349.0 | |
| 0.00 | 2.06 | 0.00 | 1.83 | -15.10 | 225.54 | -55.61 | 106.09 | 0.8313 | -730.0 | -584.0 | |
| 0.00 | 1.70 | 0.00 | 1.51 | -14.82 | 225.60 | -55.55 | 105.76 | 0.8305 | 206.0 | -1.2 | |
| 0.54 | 1.52 | 0.51 | 1.44 | -18.91 | 223.58 | -57.57 | 110.30 | 0.8535 | -490.2 | -463.8 | |
| 0.00 | 1.70 | 0.00 | 1.53 | -15.58 | 225.12 | -56.03 | 106.61 | 0.8357 | -476.0 | -441.7 | |
| 0.00 | 2.51 | 0.00 | 2.25 | -15.26 | 225.14 | -56.01 | 106.24 | 0.8353 | -605.0 | -488.9 | |
| 0.00 | 0.81 | 0.00 | 0.77 | -18.96 | 223.19 | -57.96 | 110.30 | 0.8568 | -509.0 | -472.7 | |
| 0.36 | 1.34 | 0.32 | 1.21 | -15.34 | 224.82 | -56.33 | 106.29 | 0.8383 | -391.0 | -336.9 | |
| 0.00 | 1.52 | 0.00 | 1.38 | -14.90 | 224.77 | -56.38 | 105.76 | 0.8382 | -387.0 | -335.0 | |
| 0.00 | 0.90 | 0.00 | 0.82 | -14.35 | 224.31 | -56.84 | 105.05 | 0.8420 | -470.0 | -367.0 | |
| 11.47 | 58.76 | 11.02 | 56.62 | -17.19 | 222.67 | -58.48 | 108.18 | 0.8592 | 684.9 | 111.1 | |
| 0.00 | 1.25 | 0.00 | 1.17 | -14.41 | 223.41 | -57.74 | 105.02 | 0.8501 | -173.0 | -215.9 | |
| 0.00 | 1.43 | 0.00 | 1.37 | -14.06 | 222.60 | -58.55 | 104.53 | 0.8569 | -411.0 | -413.9 | |
| 5.73 | 7.88 | 5.56 | 7.65 | -14.72 | 222.07 | -59.07 | 105.24 | 0.8620 | -489.2 | -259.0 | |
| 0.99 | 2.78 | 0.95 | 2.68 | -13.69 | 222.14 | -59.00 | 104.06 | 0.8606 | -511.7 | -425.2 | |
| 0.00 | 3.40 | 0.00 | 3.55 | -17.95 | 219.96 | -61.19 | 108.70 | 0.8820 | -536.0 | -434.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
