SDO HMI 2014-05-11 18:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.75 | 99.29 | 37.42 | 162.16 | -24.13 | 193.70 | -72.01 | 114.39 | 0.9535 | 244.5 | 68.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-11 18:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.79 | 90.41 | 32.50 | 142.12 | -23.94 | 194.64 | -71.07 | 114.25 | 0.9496 | 402.6 | 112.7 | |
| 0.00 | 0.90 | 0.00 | 1.53 | -24.32 | 192.92 | -72.80 | 114.51 | 0.9580 | 29.0 | 19.7 | |
| 0.00 | 1.52 | 0.00 | 2.40 | -23.10 | 194.28 | -71.44 | 113.33 | 0.9510 | -453.0 | -311.5 | |
| 2.96 | -1.00 | 4.92 | -1.00 | -23.74 | 193.30 | -72.41 | 113.93 | 0.9560 | -171.0 | 999999 | |
| 0.00 | 3.05 | 0.00 | 7.61 | -26.74 | 187.03 | -78.68 | 116.68 | 0.9809 | -294.0 | -273.2 | |
| 0.00 | 0.90 | 0.00 | 2.41 | -26.93 | 185.97 | -79.74 | 116.83 | 0.9840 | -82.0 | -61.2 | |
| 0.00 | 0.90 | 0.00 | 1.60 | -23.75 | 192.03 | -73.69 | 113.85 | 0.9617 | -465.0 | -414.0 | |
| 0.00 | 0.27 | 0.00 | 0.69 | -25.54 | 186.69 | -79.02 | 115.44 | 0.9818 | -169.0 | -172.0 | |
| 0.00 | 1.34 | 0.00 | 3.80 | -25.85 | 185.48 | -80.24 | 115.72 | 0.9852 | 53.0 | 120.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
