SDO HMI 2014-05-12 19:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.49 | 171.05 | 34.46 | 165.16 | -23.84 | 194.56 | -57.38 | 116.17 | 0.8599 | 555.8 | 234.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-12 19:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.46 | 161.00 | 30.04 | 153.96 | -23.78 | 194.98 | -56.96 | 116.18 | 0.8568 | 781.5 | 269.1 | |
| 0.99 | -1.00 | 0.96 | -1.00 | -23.84 | 194.07 | -57.87 | 116.05 | 0.8642 | -109.6 | 999999 | |
| 1.43 | -1.00 | 1.40 | -1.00 | -23.68 | 194.06 | -57.88 | 115.86 | 0.8640 | 175.2 | 999999 | |
| 0.00 | 2.15 | 0.00 | 2.11 | -23.50 | 193.80 | -58.13 | 115.61 | 0.8657 | -267.0 | -173.6 | |
| 0.00 | 0.81 | 0.00 | 0.83 | -24.27 | 192.47 | -59.47 | 116.22 | 0.8772 | 340.0 | 250.6 | |
| 0.00 | 0.90 | 0.00 | 0.91 | -23.15 | 192.52 | -59.42 | 114.97 | 0.8751 | -199.0 | -251.6 | |
| 0.00 | 1.70 | 0.00 | 1.66 | -20.48 | 193.49 | -58.45 | 112.10 | 0.8636 | -148.0 | -158.1 | |
| 0.00 | 0.99 | 0.00 | 1.22 | -26.49 | 187.03 | -64.90 | 117.72 | 0.9173 | -349.0 | -284.4 | |
| 1.61 | 3.50 | 2.06 | 4.47 | -26.92 | 186.07 | -65.87 | 118.04 | 0.9236 | -515.2 | -437.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
