SDO HMI 2014-05-14 04:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 50.18 | 258.37 | 34.21 | 177.45 | -23.78 | 193.95 | -39.78 | 122.21 | 0.6940 | 602.5 | 251.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-14 04:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.08 | 0.00 | 0.72 | -22.00 | 195.18 | -38.56 | 120.40 | 0.6723 | -116.0 | -120.4 | |
| 48.29 | 242.36 | 32.91 | 165.37 | -23.70 | 194.38 | -39.35 | 122.30 | 0.6893 | 998.7 | 305.4 | |
| 1.89 | -2.00 | 1.30 | -2.00 | -23.45 | 193.70 | -40.04 | 121.62 | 0.6954 | 417.0 | 999999 | |
| 0.00 | 1.44 | 0.00 | 0.99 | -23.21 | 193.39 | -40.34 | 121.16 | 0.6975 | 165.0 | 140.6 | |
| 0.00 | 0.72 | 0.00 | 0.50 | -23.31 | 192.22 | -41.52 | 120.73 | 0.7105 | 266.0 | 361.8 | |
| 0.00 | 1.08 | 0.00 | 0.77 | -23.66 | 191.14 | -42.59 | 120.71 | 0.7233 | -539.0 | -375.6 | |
| 0.00 | 2.51 | 0.00 | 1.85 | -23.38 | 189.34 | -44.40 | 119.58 | 0.7407 | -404.0 | -296.8 | |
| 0.00 | 0.63 | 0.00 | 0.48 | -25.99 | 187.83 | -45.90 | 122.26 | 0.7656 | -639.0 | -560.0 | |
| 0.00 | 1.53 | 0.00 | 1.18 | -25.81 | 187.44 | -46.30 | 121.88 | 0.7687 | -617.0 | -491.2 | |
| 0.00 | 1.35 | 0.00 | 1.06 | -26.42 | 186.72 | -47.01 | 122.34 | 0.7776 | -680.0 | -525.3 | |
| 0.00 | 1.44 | 0.00 | 1.13 | -26.05 | 186.43 | -47.31 | 121.77 | 0.7790 | -582.0 | -505.2 | |
| 0.00 | 1.35 | 0.00 | 1.08 | -26.32 | 185.72 | -48.01 | 121.84 | 0.7865 | -562.0 | -486.1 | |
| 0.00 | 1.17 | 0.00 | 0.96 | -27.86 | 184.61 | -49.12 | 123.28 | 0.8018 | -538.0 | -560.2 | |
| 0.00 | 0.81 | 0.00 | 0.64 | -25.92 | 185.74 | -48.00 | 121.37 | 0.7850 | -503.0 | -411.4 | |
| 0.00 | 0.90 | 0.00 | 0.72 | -25.01 | 185.22 | -48.52 | 120.07 | 0.7868 | -218.0 | -243.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
