SDO HMI 2014-05-15 02:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 109.39 | 635.66 | 55.86 | 325.34 | -14.27 | 228.57 | 6.96 | 210.02 | 0.2489 | 158.3 | 117.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-15 02:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.72 | 0.00 | 0.42 | -6.34 | 252.64 | 31.03 | 262.17 | 0.5193 | 578.0 | 484.5 | |
| 0.00 | 2.24 | 0.00 | 1.30 | -10.87 | 251.90 | 30.29 | 253.29 | 0.5192 | -789.0 | -666.4 | |
| 0.00 | 1.17 | 0.00 | 0.63 | -10.50 | 244.14 | 22.53 | 249.68 | 0.4035 | 358.0 | 413.2 | |
| 0.00 | 1.17 | 0.00 | 0.63 | -11.59 | 243.26 | 21.65 | 246.38 | 0.3961 | 812.0 | 712.2 | |
| 0.00 | 1.62 | 0.00 | 0.85 | -6.93 | 240.27 | 18.66 | 256.45 | 0.3281 | 807.0 | 698.9 | |
| 0.00 | 1.44 | 0.00 | 0.75 | -7.29 | 238.36 | 16.75 | 253.94 | 0.2988 | 742.0 | 476.8 | |
| 0.54 | 1.71 | 0.28 | 0.88 | -9.96 | 237.13 | 15.52 | 244.05 | 0.2944 | 889.7 | 687.8 | |
| 0.00 | 1.98 | 0.00 | 1.03 | -11.40 | 236.76 | 15.15 | 239.13 | 0.2997 | 891.0 | 693.6 | |
| 0.00 | 0.99 | 0.00 | 0.52 | -14.51 | 236.75 | 15.14 | 230.77 | 0.3279 | 702.0 | 514.5 | |
| 0.00 | 0.36 | 0.00 | 0.19 | -9.93 | 236.36 | 14.76 | 243.02 | 0.2828 | 817.0 | 795.0 | |
| 0.36 | 3.68 | 0.19 | 1.90 | -11.28 | 236.17 | 14.56 | 238.53 | 0.2904 | 831.5 | 719.8 | |
| 0.00 | 1.89 | 0.00 | 0.98 | -13.34 | 236.26 | 14.65 | 232.85 | 0.3100 | 835.0 | 579.0 | |
| 0.00 | 3.68 | 0.00 | 1.90 | -11.26 | 235.85 | 14.24 | 238.06 | 0.2856 | 624.0 | 594.0 | |
| 0.00 | 1.98 | 0.00 | 1.03 | -13.01 | 235.88 | 14.27 | 233.07 | 0.3019 | 682.0 | 543.1 | |
| 0.00 | 3.23 | 0.00 | 1.66 | -7.93 | 235.46 | 13.85 | 248.63 | 0.2558 | 956.0 | 839.9 | |
| 0.00 | 0.99 | 0.00 | 0.51 | -13.63 | 235.57 | 13.96 | 230.80 | 0.3038 | 759.0 | 655.6 | |
| 0.00 | 1.71 | 0.00 | 0.87 | -7.90 | 235.27 | 13.66 | 248.48 | 0.2526 | 809.0 | 626.2 | |
| 0.00 | 1.80 | 0.00 | 0.93 | -13.14 | 235.25 | 13.64 | 231.50 | 0.2947 | 825.0 | 623.0 | |
| 0.00 | 2.96 | 0.00 | 1.54 | -14.62 | 235.18 | 13.57 | 227.49 | 0.3093 | 792.0 | 672.3 | |
| 0.00 | 1.89 | 0.00 | 0.96 | -5.42 | 234.80 | 13.19 | 257.85 | 0.2334 | 914.0 | 616.6 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -5.66 | 234.68 | 13.07 | 256.72 | 0.2323 | 816.0 | 666.7 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -10.13 | 234.76 | 13.15 | 239.70 | 0.2605 | -425.0 | -260.2 | |
| 1.62 | 8.08 | 0.83 | 4.14 | -10.47 | 234.45 | 12.84 | 237.99 | 0.2590 | -422.2 | 356.6 | |
| 0.00 | 2.69 | 0.00 | 1.38 | -10.84 | 234.03 | 12.42 | 235.90 | 0.2562 | 750.0 | 702.8 | |
| 0.00 | 1.26 | 0.00 | 0.64 | -6.76 | 233.86 | 12.25 | 251.10 | 0.2237 | 770.0 | 540.6 | |
| 0.00 | 1.26 | 0.00 | 0.65 | -11.82 | 234.04 | 12.43 | 232.80 | 0.2656 | 718.0 | 489.3 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -6.82 | 233.71 | 12.10 | 250.62 | 0.2216 | 728.0 | 557.4 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -20.72 | 234.25 | 12.64 | 213.38 | 0.3736 | 597.0 | 408.1 | |
| 0.00 | 0.90 | 0.00 | 0.45 | -4.98 | 233.08 | 11.47 | 258.33 | 0.2032 | 847.0 | 686.5 | |
| 0.00 | 2.15 | 0.00 | 1.12 | -15.94 | 233.45 | 11.84 | 220.60 | 0.3046 | 675.0 | 534.0 | |
| 0.00 | 0.72 | 0.00 | 0.36 | -4.80 | 232.92 | 11.31 | 259.07 | 0.2000 | 864.0 | 612.0 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -10.34 | 232.09 | 10.48 | 233.18 | 0.2245 | -871.0 | -720.6 | |
| 0.00 | 1.71 | 0.00 | 0.87 | -10.16 | 232.05 | 10.44 | 233.76 | 0.2222 | -921.0 | -775.2 | |
| 0.00 | 0.90 | 0.00 | 0.45 | -9.70 | 231.13 | 9.52 | 233.01 | 0.2051 | -876.0 | -709.8 | |
| 0.00 | 1.98 | 0.00 | 1.00 | -11.72 | 231.04 | 9.43 | 225.48 | 0.2260 | -875.0 | -670.6 | |
| 0.00 | 1.35 | 0.00 | 0.68 | -9.95 | 230.89 | 9.28 | 231.35 | 0.2043 | -821.0 | -665.1 | |
| 0.00 | 1.44 | 0.00 | 0.73 | -12.03 | 230.80 | 9.19 | 223.77 | 0.2268 | -785.0 | -611.8 | |
| 24.96 | 344.41 | 12.76 | 176.11 | -13.85 | 230.55 | 8.94 | 217.84 | 0.2470 | 1354.0 | 445.7 | |
| 8.80 | -38.00 | 4.50 | -38.00 | -14.28 | 230.44 | 8.83 | 216.42 | 0.2516 | 1181.1 | 999999 | |
| 8.89 | -38.00 | 4.55 | -38.00 | -14.60 | 230.29 | 8.68 | 215.22 | 0.2544 | 996.5 | 999999 | |
| 20.20 | -38.00 | 10.31 | -38.00 | -13.92 | 230.11 | 8.50 | 216.30 | 0.2434 | 1443.3 | 999999 | |
| 7.36 | -38.00 | 3.76 | -38.00 | -14.32 | 230.00 | 8.39 | 214.96 | 0.2477 | 1141.9 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.41 | -11.89 | 229.51 | 7.90 | 219.99 | 0.2102 | -719.0 | -591.0 | |
| 2.42 | -38.00 | 1.24 | -38.00 | -13.73 | 229.47 | 7.86 | 214.68 | 0.2346 | 1055.2 | 999999 | |
| 0.00 | 8.98 | 0.00 | 4.57 | -13.43 | 229.08 | 7.47 | 214.12 | 0.2266 | 864.0 | 581.6 | |
| 0.00 | 14.99 | 0.00 | 7.64 | -14.01 | 228.85 | 7.24 | 211.86 | 0.2328 | 281.0 | 290.0 | |
| 0.00 | 1.35 | 0.00 | 0.68 | -13.12 | 228.79 | 7.18 | 213.86 | 0.2195 | 851.0 | 734.5 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -11.65 | 228.47 | 6.86 | 216.87 | 0.1960 | -852.0 | -733.9 | |
| 0.00 | 1.62 | 0.00 | 0.81 | -10.36 | 228.29 | 6.68 | 220.52 | 0.1769 | -701.0 | -617.6 | |
| 0.00 | 1.35 | 0.00 | 0.68 | -11.40 | 228.03 | 6.42 | 215.83 | 0.1881 | -956.0 | -726.5 | |
| 0.00 | 0.81 | 0.00 | 0.41 | -12.60 | 227.78 | 6.17 | 211.30 | 0.2028 | -816.0 | -647.8 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -12.39 | 227.68 | 6.07 | 211.47 | 0.1988 | -815.0 | -632.1 | |
| 0.90 | 1.98 | 0.46 | 1.01 | -14.92 | 227.49 | 5.88 | 205.02 | 0.2351 | 938.0 | 680.2 | |
| 0.00 | 1.71 | 0.00 | 0.86 | -12.85 | 227.16 | 5.55 | 208.09 | 0.2012 | -938.0 | -650.6 | |
| 0.00 | 2.15 | 0.00 | 1.09 | -13.99 | 227.18 | 5.58 | 205.66 | 0.2187 | 722.0 | 559.7 | |
| 0.00 | 4.94 | 0.00 | 2.52 | -15.14 | 226.93 | 5.32 | 202.52 | 0.2347 | -388.0 | -553.3 | |
| 0.00 | 1.53 | 0.00 | 0.78 | -17.51 | 226.45 | 4.84 | 197.45 | 0.2695 | 763.0 | 586.1 | |
| 0.00 | 1.26 | 0.00 | 0.65 | -18.89 | 226.29 | 4.68 | 195.46 | 0.2910 | 736.0 | 644.6 | |
| 0.00 | 6.28 | 0.00 | 3.21 | -15.95 | 225.94 | 4.33 | 197.54 | 0.2418 | -116.0 | -86.0 | |
| 0.00 | 3.50 | 0.00 | 1.78 | -15.64 | 225.80 | 4.20 | 197.44 | 0.2361 | -892.0 | -766.0 | |
| 0.00 | 1.26 | 0.00 | 0.65 | -17.76 | 225.75 | 4.14 | 194.81 | 0.2703 | -750.0 | -581.8 | |
| 0.90 | 2.60 | 0.46 | 1.33 | -15.89 | 225.68 | 4.07 | 196.65 | 0.2395 | -933.2 | -691.8 | |
| 0.00 | 1.44 | 0.00 | 0.73 | -13.59 | 225.49 | 3.88 | 199.14 | 0.2013 | -811.0 | -636.4 | |
| 0.99 | 4.85 | 0.50 | 2.46 | -14.27 | 225.18 | 3.57 | 196.74 | 0.2108 | -1017.8 | -906.4 | |
| 0.72 | 1.71 | 0.36 | 0.86 | -13.32 | 225.11 | 3.50 | 197.84 | 0.1948 | -870.6 | -665.0 | |
| 0.00 | 2.15 | 0.00 | 1.10 | -17.26 | 224.95 | 3.34 | 192.46 | 0.2589 | -866.0 | -688.6 | |
| 0.00 | 1.44 | 0.00 | 0.73 | -14.65 | 224.84 | 3.24 | 194.76 | 0.2153 | -877.0 | -722.6 | |
| 0.00 | 1.35 | 0.00 | 0.68 | -14.00 | 224.77 | 3.16 | 195.27 | 0.2043 | -790.0 | -637.5 | |
| 0.00 | 0.90 | 0.00 | 0.46 | -15.42 | 224.76 | 3.15 | 193.51 | 0.2278 | -496.0 | -312.3 | |
| 0.00 | 1.17 | 0.00 | 0.60 | -17.04 | 224.72 | 3.11 | 191.82 | 0.2545 | -929.0 | -804.8 | |
| 0.00 | 5.12 | 0.00 | 2.61 | -15.86 | 224.67 | 3.06 | 192.71 | 0.2347 | -543.0 | -660.2 | |
| 0.00 | 4.85 | 0.00 | 2.47 | -16.29 | 224.68 | 3.07 | 192.32 | 0.2419 | -933.0 | -740.6 | |
| 1.08 | 43.28 | 0.55 | 21.98 | -15.20 | 224.63 | 3.02 | 193.21 | 0.2237 | -945.7 | -817.8 | |
| 1.62 | 3.86 | 0.83 | 1.98 | -16.82 | 224.59 | 2.98 | 191.52 | 0.2504 | -1100.4 | -830.7 | |
| 0.00 | 1.44 | 0.00 | 0.74 | -17.32 | 224.60 | 2.99 | 191.14 | 0.2588 | -765.0 | -550.8 | |
| 3.23 | -73.00 | 1.64 | -73.00 | -15.58 | 224.48 | 2.87 | 192.20 | 0.2293 | -968.0 | 999999 | |
| 0.90 | 8.35 | 0.46 | 4.23 | -14.71 | 224.44 | 2.83 | 192.90 | 0.2147 | -1086.7 | -714.8 | |
| 0.00 | 0.99 | 0.00 | 0.51 | -17.20 | 224.41 | 2.80 | 190.54 | 0.2561 | -830.0 | -654.5 | |
| 0.00 | 1.35 | 0.00 | 0.69 | -17.35 | 224.38 | 2.77 | 190.31 | 0.2586 | -679.0 | -572.3 | |
| 1.44 | -73.00 | 0.73 | -73.00 | -15.23 | 224.32 | 2.71 | 191.85 | 0.2231 | -1023.8 | 999999 | |
| 0.99 | 3.59 | 0.50 | 1.83 | -16.07 | 224.27 | 2.66 | 190.88 | 0.2369 | -987.4 | -771.8 | |
| 0.00 | 0.90 | 0.00 | 0.46 | -16.73 | 224.27 | 2.66 | 190.39 | 0.2479 | -774.0 | -594.8 | |
| 4.76 | -73.00 | 2.42 | -73.00 | -15.02 | 224.19 | 2.58 | 191.51 | 0.2190 | -1235.0 | 999999 | |
| 1.89 | -73.00 | 0.96 | -73.00 | -15.51 | 224.04 | 2.43 | 190.42 | 0.2268 | -1000.8 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.64 | -14.09 | 223.77 | 2.16 | 190.50 | 0.2020 | -1062.0 | -872.7 | |
| 1.53 | 3.77 | 0.77 | 1.91 | -14.99 | 223.72 | 2.11 | 189.47 | 0.2170 | -977.9 | -774.1 | |
| 0.00 | 0.63 | 0.00 | 0.32 | -14.12 | 223.56 | 1.95 | 189.43 | 0.2019 | -941.0 | -798.1 | |
| 0.45 | 7.18 | 0.23 | 3.63 | -13.87 | 223.40 | 1.79 | 188.87 | 0.1973 | -1205.0 | -925.8 | |
| 0.00 | 2.60 | 0.00 | 1.31 | -11.96 | 223.26 | 1.65 | 189.93 | 0.1645 | -987.0 | -691.0 | |
| 0.00 | 1.53 | 0.00 | 0.77 | -14.80 | 222.93 | 1.32 | 186.08 | 0.2120 | -726.0 | -615.8 | |
| 0.00 | 3.95 | 0.00 | 1.99 | -13.13 | 222.83 | 1.22 | 186.54 | 0.1834 | -931.0 | -845.2 | |
| 0.00 | 1.89 | 0.00 | 0.95 | -13.41 | 222.71 | 1.10 | 185.73 | 0.1879 | -1008.0 | -853.1 | |
| 0.00 | 2.60 | 0.00 | 1.31 | -13.56 | 222.55 | 0.94 | 184.85 | 0.1903 | -892.0 | -798.3 | |
| 12.84 | 23.70 | 6.57 | 12.13 | -17.20 | 222.50 | 0.89 | 183.40 | 0.2522 | 1153.1 | 609.5 | |
| 0.00 | 0.99 | 0.00 | 0.50 | -15.24 | 222.15 | 0.54 | 182.40 | 0.2185 | -937.0 | -779.2 | |
| 0.00 | 1.35 | 0.00 | 0.70 | -19.31 | 221.29 | -0.32 | 178.95 | 0.2873 | -784.0 | -651.9 | |
| 0.00 | 1.35 | 0.00 | 0.70 | -19.18 | 221.16 | -0.45 | 178.52 | 0.2853 | -776.0 | -634.3 | |
| 0.00 | 1.35 | 0.00 | 0.68 | -12.70 | 221.03 | -0.58 | 176.76 | 0.1750 | -934.0 | -807.9 | |
| 0.00 | 1.44 | 0.00 | 0.72 | -13.50 | 219.72 | -1.89 | 170.30 | 0.1912 | -786.0 | -559.6 | |
| 0.00 | 1.71 | 0.00 | 0.86 | -13.81 | 219.62 | -1.99 | 170.10 | 0.1967 | -790.0 | -611.7 | |
| 0.00 | 1.89 | 0.00 | 0.98 | -19.71 | 218.68 | -2.93 | 170.68 | 0.2981 | -932.0 | -744.3 | |
| 0.00 | 1.08 | 0.00 | 0.56 | -19.61 | 218.36 | -3.25 | 169.62 | 0.2974 | -873.0 | -671.1 | |
| 0.00 | 0.99 | 0.00 | 0.51 | -20.12 | 217.06 | -4.55 | 166.04 | 0.3102 | -796.0 | -658.3 | |
| 0.00 | 0.99 | 0.00 | 0.52 | -22.22 | 216.23 | -5.38 | 165.47 | 0.3472 | -839.0 | -699.0 | |
| 0.00 | 0.72 | 0.00 | 0.37 | -19.06 | 215.87 | -5.74 | 161.47 | 0.2990 | -793.0 | -646.8 | |
| 0.00 | 0.90 | 0.00 | 0.47 | -19.00 | 215.58 | -6.03 | 160.54 | 0.2995 | -732.0 | -553.0 | |
| 0.00 | 3.41 | 0.00 | 1.82 | -23.90 | 215.30 | -6.31 | 164.48 | 0.3774 | -720.0 | -659.1 | |
| 0.00 | 1.89 | 0.00 | 0.99 | -21.67 | 215.30 | -6.30 | 162.60 | 0.3427 | -806.0 | -617.9 | |
| 0.00 | 1.80 | 0.00 | 0.95 | -22.47 | 215.07 | -6.54 | 162.74 | 0.3563 | -713.0 | -586.1 | |
| 0.00 | 4.22 | 0.00 | 2.38 | -22.03 | 199.91 | -21.70 | 134.29 | 0.4808 | -315.0 | -557.8 | |
| 0.00 | 0.99 | 0.00 | 0.56 | -21.81 | 199.94 | -21.67 | 133.97 | 0.4782 | -740.0 | -585.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
