SDO HMI 2014-05-15 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 45.99 | 223.80 | 27.27 | 132.34 | 15.18 | 248.75 | 28.24 | 303.43 | 0.5491 | -456.7 | -320.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-15 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.90 | 0.00 | 0.54 | 13.12 | 251.56 | 31.05 | 297.86 | 0.5703 | 499.0 | 436.6 | |
| 0.00 | 0.45 | 0.00 | 0.27 | 15.03 | 250.65 | 30.14 | 301.56 | 0.5712 | 683.0 | 582.2 | |
| 0.00 | 0.72 | 0.00 | 0.43 | 13.71 | 250.05 | 29.54 | 299.96 | 0.5550 | 675.0 | 416.9 | |
| 0.00 | 0.99 | 0.00 | 0.60 | 17.51 | 250.05 | 29.54 | 305.81 | 0.5819 | 468.0 | 405.3 | |
| 0.00 | 1.08 | 0.00 | 0.65 | 17.60 | 249.88 | 29.37 | 306.09 | 0.5807 | 573.0 | 418.4 | |
| 36.37 | 205.10 | 21.57 | 121.52 | 15.08 | 249.00 | 28.49 | 303.03 | 0.5514 | -1052.6 | -399.2 | |
| 6.74 | -6.00 | 4.00 | -6.00 | 15.62 | 248.83 | 28.32 | 304.03 | 0.5533 | -835.4 | 999999 | |
| 2.25 | -6.00 | 1.33 | -6.00 | 15.43 | 248.69 | 28.18 | 303.85 | 0.5502 | -995.9 | 999999 | |
| 0.63 | -6.00 | 0.37 | -6.00 | 16.00 | 248.78 | 28.27 | 304.66 | 0.5556 | -582.6 | 999999 | |
| 0.00 | 2.33 | 0.00 | 1.38 | 15.74 | 248.42 | 27.91 | 304.58 | 0.5493 | -560.0 | -495.5 | |
| 0.00 | 0.63 | 0.00 | 0.36 | 11.99 | 247.57 | 27.06 | 299.14 | 0.5116 | 513.0 | 404.4 | |
| 0.00 | 0.99 | 0.00 | 0.58 | 15.88 | 247.30 | 26.79 | 305.85 | 0.5369 | -758.0 | -530.7 | |
| 0.00 | 1.17 | 0.00 | 0.67 | 13.89 | 246.33 | 25.82 | 303.55 | 0.5094 | 705.0 | 545.2 | |
| 0.00 | 0.99 | 0.00 | 0.57 | 14.48 | 246.16 | 25.65 | 304.72 | 0.5120 | 648.0 | 452.0 | |
| 0.00 | 2.60 | 0.00 | 1.49 | 13.98 | 246.07 | 25.56 | 303.97 | 0.5068 | 723.0 | 675.5 | |
| 0.00 | 1.35 | 0.00 | 0.76 | 11.01 | 245.54 | 25.04 | 299.21 | 0.4778 | 817.0 | 660.2 | |
| 0.00 | 0.99 | 0.00 | 0.56 | 12.95 | 245.23 | 24.72 | 303.05 | 0.4881 | 633.0 | 480.8 | |
| 0.00 | 0.81 | 0.00 | 0.45 | 15.32 | 241.41 | 20.90 | 311.64 | 0.4622 | 791.0 | 637.2 | |
| 0.00 | 1.35 | 0.00 | 0.75 | 15.38 | 241.04 | 20.53 | 312.22 | 0.4586 | 756.0 | 570.7 | |
| 0.00 | 1.35 | 0.00 | 0.76 | 18.29 | 239.99 | 19.48 | 318.28 | 0.4777 | 783.0 | 710.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
