SDO HMI 2014-05-15 20:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.29 | 305.97 | 35.43 | 171.73 | -23.81 | 192.76 | -18.94 | 140.85 | 0.4717 | 628.0 | 325.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-15 20:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 33.57 | 275.58 | 18.75 | 154.21 | -23.60 | 193.41 | -18.30 | 141.39 | 0.4630 | 1277.5 | 391.7 | |
| 24.33 | -1.00 | 13.66 | -1.00 | -23.98 | 192.89 | -18.81 | 141.22 | 0.4723 | 1028.8 | 999999 | |
| 1.26 | -1.00 | 0.71 | -1.00 | -23.88 | 192.28 | -19.43 | 140.20 | 0.4771 | 676.2 | 999999 | |
| 2.96 | 5.39 | 1.65 | 2.99 | -21.61 | 192.10 | -19.61 | 136.43 | 0.4546 | -957.5 | -731.9 | |
| 1.17 | 4.67 | 0.66 | 2.63 | -23.12 | 191.66 | -20.04 | 138.23 | 0.4751 | 770.5 | 610.9 | |
| 0.00 | 0.99 | 0.00 | 0.56 | -23.38 | 191.58 | -20.12 | 138.52 | 0.4786 | 599.0 | 482.8 | |
| 0.00 | 1.08 | 0.00 | 0.61 | -23.57 | 191.31 | -20.40 | 138.44 | 0.4835 | 487.0 | 400.8 | |
| 0.00 | 1.26 | 0.00 | 0.71 | -23.08 | 191.39 | -20.32 | 137.80 | 0.4775 | 638.0 | 430.1 | |
| 0.00 | 1.35 | 0.00 | 0.77 | -24.38 | 191.10 | -20.61 | 139.37 | 0.4942 | 375.0 | 404.0 | |
| 0.00 | 1.53 | 0.00 | 0.86 | -22.79 | 191.33 | -20.38 | 137.28 | 0.4751 | 613.0 | 592.0 | |
| 0.00 | 1.26 | 0.00 | 0.74 | -25.34 | 187.99 | -23.71 | 137.01 | 0.5351 | -738.0 | -643.6 | |
| 0.00 | 2.69 | 0.00 | 1.58 | -25.10 | 187.35 | -24.36 | 135.96 | 0.5394 | -576.0 | -629.5 | |
| 0.00 | 1.62 | 0.00 | 0.96 | -25.88 | 186.77 | -24.94 | 136.44 | 0.5526 | -775.0 | -589.8 | |
| 0.00 | 0.81 | 0.00 | 0.48 | -25.26 | 186.91 | -24.80 | 135.71 | 0.5453 | -673.0 | -485.0 | |
| 0.00 | 1.89 | 0.00 | 1.13 | -26.84 | 186.43 | -25.27 | 137.40 | 0.5650 | -811.0 | -640.2 | |
| 0.00 | 1.08 | 0.00 | 0.64 | -24.99 | 186.71 | -25.00 | 135.12 | 0.5449 | -749.0 | -618.2 | |
| 0.00 | 1.08 | 0.00 | 0.64 | -26.04 | 186.47 | -25.24 | 136.35 | 0.5571 | -764.0 | -613.1 | |
| 0.00 | 1.26 | 0.00 | 0.75 | -26.05 | 185.49 | -26.21 | 135.38 | 0.5671 | -705.0 | -520.7 | |
| 0.00 | 0.72 | 0.00 | 0.43 | -26.42 | 185.36 | -26.34 | 135.75 | 0.5716 | -826.0 | -693.8 | |
| 0.00 | 1.08 | 0.00 | 0.65 | -27.01 | 185.10 | -26.60 | 136.30 | 0.5796 | -625.0 | -453.7 | |
| 0.00 | 0.63 | 0.00 | 0.39 | -27.69 | 183.76 | -27.94 | 135.93 | 0.5987 | -586.0 | -511.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
