SDO HMI 2014-05-16 01:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 60.17 | 302.89 | 33.21 | 167.76 | -23.87 | 192.55 | -16.38 | 144.83 | 0.4486 | 544.0 | 349.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-16 01:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.27 | 271.77 | 0.15 | 150.04 | -23.29 | 193.40 | -15.54 | 145.29 | 0.4338 | 1284.7 | 416.5 | |
| 31.52 | -1.00 | 17.37 | -1.00 | -23.64 | 193.25 | -15.68 | 145.55 | 0.4395 | 1274.0 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.54 | -22.64 | 192.93 | -16.00 | 143.55 | 0.4301 | 616.0 | 593.5 | |
| 24.61 | -1.00 | 13.62 | -1.00 | -23.96 | 192.73 | -16.21 | 145.15 | 0.4481 | 1029.1 | 999999 | |
| 0.63 | -1.00 | 0.35 | -1.00 | -23.92 | 192.11 | -16.82 | 144.12 | 0.4532 | 730.9 | 999999 | |
| 2.78 | 4.13 | 1.52 | 2.26 | -21.50 | 192.08 | -16.86 | 140.39 | 0.4249 | -967.2 | -710.7 | |
| 0.00 | 1.62 | 0.00 | 0.90 | -23.59 | 191.74 | -17.19 | 143.07 | 0.4527 | 672.0 | 484.6 | |
| 0.00 | 0.99 | 0.00 | 0.54 | -22.26 | 191.71 | -17.22 | 141.02 | 0.4375 | -533.0 | -424.8 | |
| 0.36 | 5.75 | 0.20 | 3.19 | -23.23 | 191.34 | -17.59 | 141.93 | 0.4523 | 966.2 | 790.5 | |
| 0.00 | 2.34 | 0.00 | 1.29 | -22.87 | 191.11 | -17.82 | 141.04 | 0.4504 | 661.0 | 573.4 | |
| 0.00 | 0.99 | 0.00 | 0.57 | -25.37 | 187.89 | -21.04 | 140.25 | 0.5093 | -754.0 | -643.7 | |
| 0.00 | 2.07 | 0.00 | 1.19 | -25.23 | 187.42 | -21.52 | 139.46 | 0.5125 | -914.0 | -630.6 | |
| 0.00 | 0.81 | 0.00 | 0.47 | -25.12 | 187.08 | -21.86 | 138.89 | 0.5148 | -764.0 | -554.4 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -25.94 | 186.84 | -22.09 | 139.75 | 0.5255 | -742.0 | -620.8 | |
| 0.00 | 1.71 | 0.00 | 1.00 | -26.60 | 186.53 | -22.41 | 140.27 | 0.5354 | -836.0 | -660.3 | |
| 0.00 | 1.26 | 0.00 | 0.74 | -27.47 | 186.23 | -22.71 | 141.07 | 0.5471 | -528.0 | -453.8 | |
| 0.00 | 1.26 | 0.00 | 0.74 | -26.97 | 186.30 | -22.63 | 140.49 | 0.5412 | -814.0 | -671.9 | |
| 0.00 | 0.45 | 0.00 | 0.27 | -28.71 | 185.87 | -23.06 | 142.24 | 0.5632 | -644.0 | -524.6 | |
| 0.00 | 0.63 | 0.00 | 0.37 | -26.42 | 185.42 | -23.51 | 138.76 | 0.5440 | -737.0 | -630.1 | |
| 0.00 | 1.26 | 0.00 | 0.73 | -24.99 | 185.36 | -23.58 | 136.70 | 0.5307 | -757.0 | -677.4 | |
| 0.00 | 0.90 | 0.00 | 0.54 | -28.40 | 183.98 | -24.95 | 139.81 | 0.5772 | -565.0 | -511.0 | |
| 0.00 | 0.99 | 0.00 | 0.60 | -28.03 | 183.85 | -25.09 | 139.19 | 0.5748 | -725.0 | -573.1 | |
| 0.00 | 0.90 | 0.00 | 0.55 | -28.33 | 183.62 | -25.32 | 139.34 | 0.5798 | -678.0 | -636.8 | |
| 0.00 | 1.17 | 0.00 | 0.71 | -28.06 | 183.54 | -25.40 | 138.90 | 0.5780 | -767.0 | -638.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
