SDO HMI 2014-05-16 14:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 49.76 | 297.40 | 26.80 | 160.51 | -23.99 | 192.33 | -9.47 | 157.81 | 0.3982 | 739.2 | 376.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-16 14:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.76 | 279.41 | 14.39 | 150.50 | -23.70 | 192.86 | -8.94 | 158.54 | 0.3907 | 1370.7 | 421.5 | |
| 1.62 | -1.00 | 0.87 | -1.00 | -24.16 | 192.79 | -9.01 | 158.86 | 0.3978 | 802.3 | 999999 | |
| 19.94 | -1.00 | 10.76 | -1.00 | -24.06 | 192.39 | -9.41 | 157.92 | 0.3987 | 1092.4 | 999999 | |
| 1.44 | -1.00 | 0.78 | -1.00 | -23.92 | 191.63 | -10.17 | 156.19 | 0.4015 | 750.0 | 999999 | |
| 0.00 | 1.35 | 0.00 | 0.73 | -23.59 | 191.12 | -10.68 | 154.77 | 0.4001 | 740.0 | 682.9 | |
| 0.00 | 1.35 | 0.00 | 0.73 | -23.75 | 191.07 | -10.73 | 154.86 | 0.4028 | 508.0 | 393.4 | |
| 0.00 | 1.71 | 0.00 | 0.92 | -23.27 | 191.08 | -10.72 | 154.30 | 0.3958 | 885.0 | 722.2 | |
| 0.00 | 1.17 | 0.00 | 0.63 | -22.91 | 190.94 | -10.86 | 153.58 | 0.3917 | 815.0 | 689.4 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -25.12 | 190.64 | -11.16 | 155.55 | 0.4250 | 744.0 | 593.1 | |
| 0.00 | 1.35 | 0.00 | 0.73 | -23.35 | 189.18 | -12.62 | 150.66 | 0.4109 | -861.0 | -740.6 | |
| 0.00 | 0.99 | 0.00 | 0.55 | -25.22 | 187.51 | -14.29 | 150.04 | 0.4490 | -753.0 | -623.8 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -23.58 | 187.15 | -14.65 | 147.29 | 0.4307 | -745.0 | -626.4 | |
| 0.00 | 1.80 | 0.00 | 1.02 | -27.43 | 186.09 | -15.71 | 150.39 | 0.4883 | -682.0 | -586.5 | |
| 0.00 | 1.26 | 0.00 | 0.71 | -27.06 | 186.00 | -15.80 | 149.83 | 0.4843 | -876.0 | -773.3 | |
| 0.00 | 2.60 | 0.00 | 1.48 | -27.23 | 185.87 | -15.93 | 149.82 | 0.4874 | -842.0 | -773.9 | |
| 0.00 | 0.36 | 0.00 | 0.20 | -27.66 | 185.38 | -16.42 | 149.59 | 0.4966 | -634.0 | -534.0 | |
| 0.00 | 0.81 | 0.00 | 0.47 | -28.65 | 183.74 | -18.06 | 148.41 | 0.5215 | -536.0 | -435.4 | |
| 0.00 | 1.35 | 0.00 | 0.81 | -31.85 | 182.09 | -19.71 | 149.80 | 0.5717 | -364.0 | -407.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
