SDO HMI 2014-05-17 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 76.95 | 170.07 | 39.27 | 86.75 | -15.99 | 194.33 | 2.47 | 189.79 | 0.2399 | 106.9 | 233.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-17 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.65 | 62.20 | 3.41 | 31.85 | -16.71 | 195.74 | 3.87 | 194.67 | 0.2565 | 1175.8 | 675.2 | |
| 1.89 | -1.00 | 0.97 | -1.00 | -16.21 | 195.73 | 3.86 | 195.17 | 0.2483 | 1123.1 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.64 | -15.65 | 195.69 | 3.82 | 195.65 | 0.2389 | 741.0 | 559.5 | |
| 1.08 | -1.00 | 0.55 | -1.00 | -16.02 | 195.60 | 3.73 | 194.89 | 0.2446 | 1072.5 | 999999 | |
| 3.24 | -1.00 | 1.66 | -1.00 | -16.43 | 195.57 | 3.71 | 194.36 | 0.2512 | 1160.2 | 999999 | |
| 19.86 | -1.00 | 10.19 | -1.00 | -16.93 | 195.49 | 3.62 | 193.55 | 0.2591 | 1140.7 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -15.84 | 195.47 | 3.60 | 194.59 | 0.2410 | 963.0 | 746.0 | |
| 0.00 | 1.98 | 0.00 | 1.01 | -15.65 | 195.37 | 3.51 | 194.42 | 0.2375 | 943.0 | 700.0 | |
| 0.00 | 3.95 | 0.00 | 2.03 | -16.87 | 194.92 | 3.05 | 191.53 | 0.2559 | 828.0 | 618.2 | |
| 0.00 | 1.35 | 0.00 | 0.69 | -16.40 | 194.78 | 2.92 | 191.42 | 0.2477 | 421.0 | 267.1 | |
| 0.00 | 0.81 | 0.00 | 0.41 | -12.80 | 194.55 | 2.69 | 194.22 | 0.1869 | -862.0 | -635.1 | |
| 0.00 | 3.33 | 0.00 | 1.70 | -16.80 | 194.53 | 2.67 | 190.16 | 0.2537 | 905.0 | 680.4 | |
| 0.00 | 0.90 | 0.00 | 0.46 | -15.34 | 194.30 | 2.43 | 190.36 | 0.2284 | -691.0 | -407.8 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -15.52 | 194.20 | 2.34 | 189.83 | 0.2313 | -718.0 | -480.2 | |
| 5.75 | 86.83 | 2.92 | 44.17 | -15.06 | 193.76 | 1.89 | 188.29 | 0.2222 | 824.3 | -71.3 | |
| 7.10 | -15.00 | 3.61 | -15.00 | -15.43 | 193.73 | 1.87 | 187.93 | 0.2285 | -1024.3 | 999999 | |
| 21.57 | -15.00 | 10.97 | -15.00 | -15.43 | 193.35 | 1.49 | 186.34 | 0.2277 | -896.7 | 999999 | |
| 3.51 | -15.00 | 1.79 | -15.00 | -15.84 | 193.29 | 1.43 | 185.89 | 0.2344 | -971.4 | 999999 | |
| 3.42 | -15.00 | 1.74 | -15.00 | -15.74 | 193.13 | 1.27 | 185.28 | 0.2326 | -934.2 | 999999 | |
| 0.00 | 0.45 | 0.00 | 0.23 | -15.87 | 192.95 | 1.08 | 184.46 | 0.2344 | -475.0 | -391.4 | |
| 2.88 | 4.76 | 1.46 | 2.42 | -15.31 | 192.50 | 0.64 | 182.76 | 0.2244 | -1051.8 | -748.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
